How do I choose a golf simulator projector?
Typically in a golf simulator you need to seek a ‘short throw’ projector which has a throw ratio of between 0.4 and 1.0. exactly where you intend to hit from. This should be marked out early within your simulator setup and everything else will be built around it.
How far should a projector be from the screen in golf?
This equation means you can work out how far your projector should be from your screen in your golf simulator by multiplying your horizontal image width by the projector’s throw ratio. What kind of projector do I need for a golf simulator?
How far should I mount my projector from my simulators?
This short-throw projector has a throw ratio of 0.5, which means to achieve a horizontal impact screen image width of 14ft, you’d need to mount the projector 7ft away. Next, you need to decide which actual position in your simulator you need to mount the projector.
Can a golf ball hit a projector?
It’s worth noting that if your projector isn’t offset, a floor mount projector tends to get hit more by the golf ball while a ceiling mount projector is affected by the golf club. How far does a golf projector screen have to be from the wall?

Where should a projector be placed on a golf simulator?
We'd suggest mounting your projector on the ceiling or your enclosure centered on your impact screen, but if you do place the projector off to the side so that that image looks distorted or skewed, you should check your projector's settings for keystone controls.
How far away should I mount a projector?
You can calculate this position by multiplying the throw distance number (in this example, 1.3) by the horizontal length of your screen (not diagonal). For example, if your screen is 87” wide and the throw distance of your projector is 1.3, the projector should be 113” (87x1. 3=113”) from the screen.
How far back should SkyTrak be from screen?
For SkyTrak, the minimum recommended distance from the screen is approximately 6 feet. This will prevent you from coming into the firing line when the ball bounces back off the wall. However, the recommended SkyTrak distance from the screen is 12 feet to 15 feet.
Can I use my projector as a golf simulator?
As a general rule of thumb, you can get by in dark rooms with lumens above 2000+ but we typically recommend getting a projector above 3000+ for the best golf simulation experience. Throw ratio refers to the distance the projector is from the screen versus how diagonally wide the screen is.
How far does projector have to be from 120 screen?
Projection DistanceScreen or image sizeProjection distance (1) Minimum to MaximumScrew hole number (2)80 inches (203 cm)110 to 121 inches (281 to 306 cm)4100 inches (254 cm)138 to 151 inches (351 to 383 cm)3120 inches (305 cm)166 to 181 inches (422 to 461 inches)2150 inches (381 cm)208 to 227 inches (529 to 577 cm)1
How far should you sit from 120 inch screen?
12 footIf your family likes being near the center of the theater, then choose a screen size which has about 10 inches of diagonal for each foot of viewing distance. That's about 120-inch diagonal for a 12 foot viewing distance.
How far should a screen be from a golf simulator?
Your impact screen should be 12-16” away from the wall behind it. Then, it's a best practice to place your tee 10-15' away from the impact screen. Lastly, make sure you have enough room behind the tee to swing easily. In total, that's at least 15' deep is ideal for a golf simulator room.
How much space do you need for foresight golf simulator?
Minimum space requirements for the Foresight GC3 are essentially the same as the minimum space requirements for a golf simulator in general. I recommend minimum dimensions of 12ft in length, 10ft in width, and 9ft in height. Some taller golfers or those with taller swings will require more height.
How much clearance do you need for a golf simulator?
The minimum space required to set up most golf simulators is 10'W x 10'L x 8.5'H. Things like player height and arm length can factor into how much space is required. If you are a shorter player, then you might be able to get away with a slightly shorter ceiling.
How many lumens do I need for a golf simulator projector?
If you plan to keep your room dark, we recommend a projector with no less than 2000 lumens. It would be wise to invest in a projector that produces 3000+ lumens, so you can be sure that you'll have a bright and clear image at all times.
Do you need a 4K projector for golf simulator?
For the best widescreen experience, a 4K projector will create an immersive image even on impact screen larger than 13 feet wide. This is especially important if you are using a high-end system simulators optimized for use with software such as E6 CONNECT or TGC 2019 that supports 4K outputs.
Does a golf simulator need a short throw projector?
However, another pointed out that you'll usually need a short throw projector (for reasons we'll cover below), and few short throw models offer sufficient horizontal lens shift or keystone adjustment to square off the picture when the projector is sufficiently far off to the side.
How is throw ratio calculated?
The throw ratio is equal to the throw distance divided by the horizontal image width of your projected image. This equation means you can work out...
What kind of projector do I need for a golf simulator?
You need a short-throw projector. This means a throw ratio of between 0.4-1.0. A projector with a throw ratio of 0.5 will give you a horizontal scr...
How tall should a golf simulator ceiling be?
The minimum height you need for your simulator would be 8.5ft (2.59m) and a comfortable height more like 10ft. Height is comfortably the most impor...
How big is a golf simulator?
The absolute minimum dimensions you need for your golf simulator are 12ft (3.65m) long x 10ft (3.05m) wide x 8.5 ft (m) high. There are many reason...
How much room do you need for Skytrak?
The absolute minimum dimensions you need for your golf simulator such as Skytrak are 12ft (3.65m) long x 10ft (3.05m) wide x 8.5 ft (m) high. There...
How tall is a golf simulator?
The minimum required room height for a golf simulator is 102 inches (259.08 cm). This is ideally the recommended size for tall players as well as players of average size. However, for short players, the ceiling height of your golf simulator can be slightly smaller than the standard height.
What is the throw distance of a projector?
The throw distance refers to the distance of the projector from the screen. If a projector has a throw ratio of 2 and if the image has a width of 12 inches (30.48 cm), the projector will have to be 24 inches (60.96 cm) away from the screen. In other words, the throw distance in inches should be double the width of the desired image projection.
Why is a short throw projector good?
A short-throw projector works best when space is an issue and prevents shadows from being displayed on the screen.
What aspect ratio is a projector?
A projector often supports a 16:9 or a 4:3 aspect ratio. The ratio can be switched from one to the other with a compromise on the resolution. It’s best to get a projector that has a native aspect ratio that matches the preferred screen size as much as possible.
Do you need a short throw projector for a golf simulator?
Does a golf simulator need a short-throw projector? While it’s not necessary for a golf simulator to have a short-throw projector , using this type of projector has its advantages. A short-throw projector prevents shadows from being displayed on the screen.
Can you mount a golf simulator on a ceiling?
If you want to adopt the traditional method of mounting the golf simulator projector, you may consider the ceiling mount option. This option is also ideal if floor mounting will not work out for reasons such as lack of space, etc.
Can you use a wireless projector on a simulator?
You can opt for a wireless projector or one that supports a variety of connectivity options. Choose a projector that can be connected to your simulator without any hassles. As a wireless projector isn’t always the fastest option, consider opting for a projector with HDMI connectivity.
How far should you swing to screen for Skytrak?
However, you really only technically need space to swing. The minimum tee to screen distance for Skytrak is probably around 6ft to avoid bounceback problems.
How much space do you need for impact screen?
You need around 1ft of the space behind your impact screen to allow deformation of the screen when struck with a golf ball. This minimises bounceback and noise, as the ball is not likely to travel into the net and still strike the wall behind.
How far behind the tee is Mevo Plus?
Flightscope recommends that Mevo Plus sits 7 feet (2.1 meters) behind the tee, though it is also recommended that you move it closer to the tee as you move down from a driver to a wedge, the tee to Mevo Plus distance comes down to 4ft for your shortest clubs. Mevo Plus works by monitoring how the ball flies.
How far should a QED be from a tee?
17ft is the minimum recommended room length for a Uneekor QED golf simulator. Uneekor recommend 10ft from tee to screen to avoid bounceback problems. You can probably get away with less tee to screen distance though. The QED must be mounted 3.5ft behind the golfer.
How long is the shortest room on a Uneekor eye xo?
16ft is the shortest room length that is recommended for a Uneekor EYE XO golf simulator. Uneekor recommend 10ft of tee to screen distance but you can probably work with less. You still need room to swing, room for the ball to fly, impact the screen and a little room behind.
What happens if you hit too far from the screen?
If you position your hitting area too far from the screen, you run the risk of missing your screen (and even enclosure) altogether with a shank or other poor shot. This would be quite embarrassing if you have friends round.
Do you need a radar launch monitor for a golf simulator?
You will require more distance behind the golfer in a golf simulator if you choose a radar based launch monitor such as Mevo Plus or Trackman. These launch monitors require enough room length to be able to view the initial flight of the ball and accurately record the launch direction, speed and spin.
Where should I mount a golf simulator projector?
The ideal position to mount your golf simulator projector is above the golfer and in line with the centre of the impact screen. This means you don’t have to rely on any keystone correction and you’ll have a beautiful centred image with optimal resolution.
What is the aspect ratio of a projector?
Aspect ratio is the ratio between the horizontal and vertical sides of your projected image. You can change the aspect ratio either in the computer settings or force the projector to display whatever is on your screen, in that aspect ratio.
What is the best accessory for a floor mounted projector?
An absolutely essential accessory for a floor mounted projector is a protective box in which it can sit. This will usually have artificial grass on the top side for added protection and aesthetics.
Can a projector be in the way of a target line?
There is a risk that the projector will be in the way of your target line and the shots you hit on a low trajectory. This problem will vanish if your room is narrow and you have to line up with your target line towards the side of your room (see above).
Should I floor mount a golf simulator?
You should definitely consider floor mounting your golf simulator projector, particularly if you struggle for height and width in your golf simulator room. Don’t forget to buy your floor mounted projector enclosure to keep you and your projector safe.
What to know before buying a golf simulator projector?
Before buying your golf simulator projector you need to make a list of your essential criteria for your setup. This means considering your room set up and planning your enclosure before buying the projector. You may need keystone correction, you may want a certain aspect ratio or resolution.
How long does a golf simulator lamp last?
They will require lamp replacement after a period of time (~1000 – 10,000 hours of use). A 10,000-hour lamp life should last you years. LED projectors are a growing sector and allow for longer periods of time between projector maintenance and light source renewal.
How many lumens does a short throw projector need?
Our recommended short throw projectors have ANSI lumens ranging from 2200 to 4200.
What is lumens in golf simulator?
Lumens are a measure of brightness. The more lumens your projector has, the brighter the image will appear on your screen. How many you need for your golf simulator depends on the specifics of your room set up. There is a complex true physical definition of the unit of 1 lumen, being a measure of luminous flux, or luminous energy per unit time.
When will laser projectors be available?
They can be a lot brighter, and have traditionally been a lot more expensive. Laser projectors are only now in 2020 making their way into the affordable home projector bracket. Two of our recommended golf simulator projectors have laser light sources.
Total vs Viewable Impact Screen Area
A golf impact screen has both a total area and a viewable area. There will almost always be a border around the screen consisting of the holes, attachments and fixings used to hang the impact screen from the golf simulator enclosure.
Aspect Ratio is Super Important
Aspect ratio is important in a golf simulator because getting it right allows you to fill your impact screen with your projected image. Golfers who mismatch their screen size, throw distance, and aspect ratio will waste areas of their impact screens with bars of empty space.
Impact Screen Size, Attaching the Screen and Bounceback
Impact screens of all sizes will need to be attached to the golf simulator enclosure frame (or room or ceiling) in the proper way in order to ensure the amount of tension in the screen is correct.
What else to Consider when buying a Golf Impact Screen
When you plan your golf simulator build, you need to decide on the following parameters early on:
