What are the dimensions of a golf cart?
A golf cart’s typical dimensions are 4 feet wide by 8 feet long and 5.5 feet high. These measurements are usually of smaller golf carts available for purchase. The dimensions of a larger golf cart that seats up to six people are 4 feet wide by 11.5 feet long and 5.5 feet tall.
Where can I buy a rear axle for my golf cart?
Golf Car Catalog offers rear axles for many golf cart brands and models including Club Car, EZGO and Yamaha, Within this section, we not only offer the entire differential assemblies, but also the side specific axles which rotate within the differential axle tubes, as well various rear axle bearings, and supplemental hardware.
Will a golf cart fit in a 4×6 trailer?
Most carts will fit in most trailers that are 5 feet wide by 9 or 10 feet long. Smaller trailers, such as the 5x8s, should also be fine. A 4×6 trailer, on the other hand, is pushing it. A golf cart’s typical dimensions are 4 feet wide by 8 feet long and 5.5 feet high. These measurements are usually of smaller golf carts available for purchase.
How big is an EZ GO RXV golf cart?
EZ-GO TXT / RXV Golf Car with Back Seat (Length 108”, Width 51”, Height 67.5”) 6" Lifted EZ-GO TXT / RXV Golf Car (Length 93”, Width 51”, Height 76”) Before you trailer your golf cart it is always a good precaution to check the grease in the wheel bearings before you haul.
How wide is a golf cart rear end?
Average Dimensions for a Golf Cart The average golf cart dimensions are around 92 x 48 x 75 inches for a standard 2 seat golf cart. The dimensions of different types of carts will vary the most in length due to the number of seats a golf cart can have.
Does a golf cart have an axle?
Axles are responsible for turning your cart's front and rear wheels by transferring power from the differential to the wheel hubs. Excessive noise or vibrating can be an indication that the driveline part may need to be replaced.
What is a rear differential on golf cart?
A golf cart rear axle, often referred to a differential, helps propel your Yamaha G1, G2, G8, G9, G14, G16, G19, G22, and G29 the drive gas or electric golf cart. A differential slows the rotational speed of your clutch or electric motor before it hits the rear wheels.
What is the differential on a golf cart?
Your differential transmits torque to the Club Car wheels and allows them to turn at different speeds. While the transmission uses internal oil pressure to change gears and efficiently transmit engine power to the driveshaft and rear axle.
How do you change a rear axle on a golf cart?
1:592:59How to Remove an E-Z-GO TXT Front and Rear Axle - YouTubeYouTubeStart of suggested clipEnd of suggested clipThe first step is to remove the rear pin from the brake cable once this is done remove the c-clipMoreThe first step is to remove the rear pin from the brake cable once this is done remove the c-clip and slide the brake cable from the assembly.
How much does it cost to replace a rear axle?
The rear axle is usually more expensive to repair or replace. It can cost anywhere from $450 to over $1,000 for the rear axle, but most people pay between $600 – $900.
Does a Go Kart need a differential?
Karts do not have a differential. The lack of a differential means that one rear tire must slide while cornering. This is achieved by designing the chassis so that the inside rear tire lifts up slightly when the kart turns the corner.
What is a Club Car DS model?
Club Car DS Club Car made body changes in 1981 and introduced the “DS” model, and this model quickly became the flagship cart of the golf cart industry. The Club Car DS front and rear body panels were constructed of plastic and fiberglass.
How do you remove the rear hub from a club car?
You can remove the rear axle snap ring on a Club Car using a pair of 90-degree snap ring pliers and a flashlight.Take off the rear wheel from the Club Car golf cart.Remove the brake drum from its place.Put the 90-degree snap ring pliers through the holes in the hub and pull at the snap ring till it comes off.
How do you fill an ezgo differential?
0:241:112002 EZGO gas golf cart Rear differential 80/90 weight oil changeYouTubeStart of suggested clipEnd of suggested clipAt the top see this yellow tab there that is a plastic plug. And you pull that plastic plug out andMoreAt the top see this yellow tab there that is a plastic plug. And you pull that plastic plug out and you fill it up with gear oil up to this hole right here.
Does a gas golf cart have a transmission?
All golf carts (much like cars) have a clutch, which is the part of the drivetrain that helps the put the power of the motor down through to the wheels/ground. Golf cart clutches are a part of the Continuously Variable Transmission (or CVT).
How big is a golf cart?
The average golf cart dimensions are around 92 x 48 x 75 inches for a standard 2 seat golf cart. The dimensions of different types of carts will vary the most in length due to the number of seats a golf cart can have. More seats added to a cart will add to its length but usually minimal amounts to the width and height.
How to store a golf cart in a garage?
If you do not have extra space in your garage or under a carport, you will need to find an alternative method for storing your golf cart. If you have limited space, a solution would be to purchase a weatherproof golf cart cover. A golf cart cover is an inexpensive way to keep your cart safe from the elements without having to build a new garage.
How wide is a golf cart?
The dimensions of an average cart are: width: 3.93 feet (1.2m) x length: 7.87 feet (2.4m) x depth: 5.9 feet (1.8M).
How much does a golf cart weigh?
On average, a golf cart weighs between 900 pounds to 1100 pounds. This is not the only scale you should directly rely upon to make your decisions because the weight will vary based on the material used and the model type. If it’s an electric vehicle with a motor and a large battery, expect 300 pounds more.
Why are electric golf carts better than electric golf carts?
An increased weight of the golf cart can provide better support, stability and are much more reliable when driving through steep terrains. The electric carts are best for short distance travels and they are also easy to drive in cold climates without starting issues.
How much weight can an electric golf cart pull?
One the other hand, electric version are cheaper, but will have reduced pulling capabilities. You can expect electric carts to pull around 150 to 180 (lbs). When buying any cart, please use it as intended. Make sure you check the maximum passenger weight that the golf cart can handle on the manufacturer’s website.
What are the different types of golf carts?
Conclusion. The weight of a golf cart varies as there are two major types of carts available. (1) Gasoline-powered push carts and (2) electric carts with large batteries. Each type has its specific advantages and disadvantages which you should analyze before making the final choice.
How many miles can a gas golf cart go?
Pros. The gas golf cart is perfect for long drives as the fuel tank, when full, can go up to 200 miles. It doesn’t incur additional expenses to replace batteries. You save lot of time because all you need to do is buy gasoline to keep it running.
How many people can a golf cart carry?
However these vehicles need to be powerful enough to carry as much as 8 people across the course without any difficulty.
What is the length of a golf cart?
The length of a golf cart is measured from the front to the back of the cart’s longest component. A two-passenger golf cart is around 8 feet or 96 inches long on average. Longer golf carts with multiple rows of seating or freight and equipment storage are also available on the market.
What is the width of a golf cart?
The width of a golf cart is measured from left to right across the cart’s widest component, including wheels but omitting any side mirrors or other extras.
What is the height of a golf cart?
The height of a golf cart is measured from the ground up at its tallest point. The height of the cart can be calculated in two ways.
Exact Dimensions
E-Z-GO was formed in 1954 and is headquartered in Augusta, Georgia, which is host to the Master’s golf tournament. The dimensions of three of the company’s most popular cart models are listed below:
Can a golf cart fit in a truck?
A full-size pickup vehicle with a four-foot bed width should be able to accommodate a cart. If the cart is a bit longer than the truck or the truck is a regular size pickup, the truck owner can leave the tailgate down to extend the length. It is critical to use a ramp to assist in loading the golf cart.
Loading a golf cart in
You should be able to load a golf cart into the bed of a truck if you have an average truck and a regular golf cart. Before packing your golf cart, be sure you know how much it weighs.
Dimensions of the Golf Cart Basket
An E-Z-GO cart basket’s typical dimensions are 18.12′′ x 10.25′′ x 17.56′′. With these measurements, fitting a cooler with 12-18 cans in the back while keeping them cold and refreshing during a game of golf should be simple. A person should be able to fit closer to 24 cans or coolers depending on the size of the cans or cooler.
How big is a golf car?
What Are the Typical Dimensions of a Golf Car? Typically, a standard golf car is four feet wide by eight feet long by six feet tall. Most weigh about 1000 pounds. Golf cars that are designed to seat four to six people, rather than just two, will usually be a bit longer than eight feet.
What is the function of a golf car?
One of the main functions of a golf car is transporting passengers and cargo. As such, it’s important to know the capacity of your car. Taking the width and length of your vehicle into account will help you to determine how many passengers or how much cargo it can accommodate.
What to consider when buying a golf car?
When buying a golf car, one of the first things you need to consider is its size . The golf car must be large enough or small enough for any of its intended functions, and you must also know its size if you want it to be compatible with any additional accessories.
Can a golf car fit in a pickup truck bed?
If your golf car needs to fit in a specific space, such as a narrow pathway or the bed of your pickup truck, it’s important to note its dimensions. The last thing you want is for your vehicle to be too large for the space in which you will use it.
Do you need to know the dimensions of your car to fit a golf cart?
If you intend to add any, from a roof to a windshield to a set of rear seats, you’ll need to know the dimensions of your car to get the proper fit. Learning how wide a golf cart is and its other must-know dimensions will help you choose the right golf car for your needs.
How fast can a golf cart go?
I have built 3 racing golf carts, so I have a fair amount of experience with them. Fist a little background. By Law a Golf Cart can go no faster than about 14 mph. There is a loophole in the Law that makes provisions up to 19/20 mph for PEV's.
Can you run a gearbox in the rear?
Get a small front wheel drive gearbox and drive shafts from any bone yard. There is no reason why it can't be run in the rear driving the rear wheels. It will be light weight. It also give the added bonus of giving a full range of gears. So top speed should no longer be an issue. The hardest part will be sorting out gear linkages. But you could even run an automatic and then gear linkages are nolonger such an issue.
How to remove the rear wheel of a golf cart?
Remove the rear wheel of the golf cart. Take off the brake drum from its place. Insert a 90-degree snap ring pliers through the holes in the hub and remove the snap ring. Slide the axle out of its position. You may require a slide hammer to help you with releasing the bearing from the axle if it’s stuck on to it.
Where is the C clip on a golf cart?
You can also check for a C-clip at the backside of the golf cart that keeps the axle in position. This clip is often inside the axle tube behind the drum mounting flange.
How to remove rear axle snap ring?
You can remove the rear axle snap ring on a Club Car using a pair of 90-degree snap ring pliers and a flashlight. Take off the rear wheel from the Club Car golf cart. Remove the brake drum from its place.
How to tell if rear axle bearing is bad?
The most common giveaway sign of a bad rear axle bearing is a loud noise coming from the axle assembly. You can try one of the following tips to solve the problem.
How to remove rear axle seal on 2002 Club Car DS?
In a 2002 Club Car DS, you can remove the rear axle seal from the axle opening by popping it out using a seal puller. If you want to install a new axle assembly, you’ll have to do the above steps followed by fitting the new assembly in place and redoing these steps once again in the reverse order.
Where is the retainer nut on a 1998 Club Car?
The axle bearing of a 1998 electric Club Car rear axle houses a retainer nut that is located inside the axle tube. This is often a C-clip and keeps the axle in position inside the tube. This C-clip or retainer nut can be accessed only using a pair of 90-degree C-clip pliers.
How to remove the shaft on a club car DS?
How to remove the axle shaft on Club Car DS. You will need a few chocks, a pair of 90-degree internal snap ring pliers, a floor jack and jack stands to remove the axle shaft on a Club Car DS. The steps given below can help you to take off the axle shaft from the golf cart. Keep the chocks before the front wheels of the Club Car.
Golf Car in a Truck Bed
Golf Carts will fit into the bed of standard pick-up and some require the rear gate to be open. King of Carts will assist you in loading the vehicle onto the truck, please make sure that you bring straps so we can secure your vehicle upon pickup. We always have loading ramps that we can load the vehicle for you.
Golf Car on a Trailer
A golf cart will fit in a 5 X 10 utility trailer without any problems, no matter if it is lifted or has a rear seat on the back.
Golf Car Transporting
When loading a golf cart on a truck bed or on a trailer you should follow these steps. Face the golf cart in the direction of the hauling vehicle, flip the windshield down and fasten a sting around the windshield. If you have to load the vehicle backwards, remove the windshield and secure the front seat bottom so it does no fly off.
