How do you glue a graphite Golf Club shaft?
The graphite shaft will come with trimming instructions that tell you how much to cut from the tip, depending on the amount of flex you want. For example, you’ll trim more off …
What to use to cut a steel golf club shaft?
May 19, 2018 · One of the most awarded / certified clubmakers shows you how to cut a steel and graphite golf shaft using a variety of tools on "Tools of the Trade"Music fro...
How to coat steel with graphite?
You can shorten the shaft of your graphite golf club by using a hacksaw or sawzall. Be sure to use caution when cutting the shaft, as this can result in serious injury if done incorrectly. There are also specialty tools available which are specifically designed to shorten the shaft of a graphite golf club.
How do you cut down a golf shaft?
When cutting a graphite shaft, it is important that you use a hack saw, or put in the special graphite shaft cutting blade on the Golfworks Shaft Cutter. Are you cutting the butt end or the tip end of the shaft? The butt end of the shaft is grip end. If you are shortening or extending the length of a golf club, this is where you will cut. If you want to change the play-ability of the club …
Why use masking tape on graphite shafts?
Secondly, by wrapping tape around the shaft, reduces the likelihood that the shaft would splinter during the last moment of the cutting process.
Can a tungsten carbide blade cut steel?
It makes thin straight cuts in all types of shaft materials used in golf. Yes, it is even strong enough to cut steel. It can cut through a graphite shaft in 15-20 seconds after the shaft has been securely place in ...
Can a rod saw blade cut steel?
It makes thin straight cuts in all types of shaft materials used in golf. Yes, it is even strong enough to cut steel.
What is a hacksaw blade?
A normal hacksaw blade has teeth that are serrated along both edges of the blade, which can splinter the fibers potentially causing breakage at a later time. Enter the rod saw blade . It possesses no teeth at all, but a rod of tungsten carbide particles enabling the blade to cut on both forward and reverse strokes.
Step 1
Determine how much of the shaft’s tip you wish to trim. The graphite shaft will come with trimming instructions that tell you how much to cut from the tip, depending on the amount of flex you want. For example, you’ll trim more off the tip to achieve a stiffer flex.
Step 2
Place the shaft into a rubber golf club clamp, then insert the clamp into a vise. The rubber protects the graphite from damage.
Step 3
Wrap two or three layers of masking or electrical tape around the area to be cut. The tape helps prevent the shaft from splintering.
Step 4
Measure the distance that you wish to trim from the tip, then mark the distance on the tape with a pen.
Step 5
Cut carefully along the marked line with a hacksaw, insuring your blade is perpendicular to the shaft. The Clubmakers.co.kr site suggests using a grit edge blade in your saw.
Step 6
Determine how much length must be trimmed from the butt end of the club. This typically depends on the type of club you're constructing. For example, the standard length of a graphite men’s 5-iron is 38 inches, while a standard 9-iron is 36 inches long, according to the Clubmakers website.
Step 7
Tape and mark the area to be cut, as you did with the tip. However, add 1/8 inch to the cut to account for the grip cap. For example, if your 9-iron shaft is 38 inches long after trimming the tip, trim 2 1/8 inches from the butt end to produce a 36-inch club after the grip is installed.
Series Navigation
I know this might seem obvious, but be sure to measure and mark off the point at which you are cutting. Especially while tipping a shaft (you can’t undo this), it is important to have precise measurements. Use a sharpie to make your marks on the shaft. Here is a tutorial on how to measure golf clubs.
Series Navigation
Hey!! I'm Zach, the founder of The DIY Golfer. I created this site in 2015 while playing D1 collegiate golf to help myself understand the game of golf better and improve as a player. Fast forward a few years, and it has become much more than a journal.
Feedback
Hey guys. I want to cut a half inch off my driver shaft. I've done a lot of searching but am not finding a definitive answer. I know you need to wrap the area you're cutting in masking tape but what's not clear to me is the correct type of blade to use. Some say hacksaw, others say a chop saw (which I have to admit, I have no idea what that is).
Feedback
i've used a dremel -- or a chop saw. either work fine. hacksaws COULD splinter the ends --not sure if it's 100% true but, i'd rather not risk it.
Feedback
I used a miter box and hacksaw with a blade with the highest number of teeth per inch (TPI) I could find at the hardware store. Came out just fine.
Feedback
What is a chop saw? I have a dremel but what attachment should be used? Also, if using a dremel, how do you get the cut perfectly straight?
Feedback
I'll use anything that has fine sharp teeth. I've done most of my shafts by hand recently because I have limited space and its easier without needing electricity and cords.
Feedback
Dremel cutoff wheel. They use a similar abrasive material circular saw blade as a chop saws uses (which is what you will find at a club maker for cutting graphite shafts). I use it for my graphite shafts as well as my carbon fiber arrows for my compound bow. Never had problems with either.
Feedback
Chop saw is best, Dremel with cutoff wheel will work (but it is tough to make an even cut), and if you use a hacksaw get a 'grit' blade.
How to shorten a golf club shaft?
To do that, the DIY golfer will have to: 1 Remove the existing grip. 2 With steel shafts, use a tubing cutter to trim the shaft; with graphite shafts, shorten using a hacksaw. 3 Re-install a grip on the newly shortened shaft. 4 And, most importantly, Wishon says, add weight to the clubhead in some manner to restore the swingweight feel of the club. "If clubs are shortened and no weight is added back to the clubhead, the chances of the length reduction having the desired effect are somewhere between slim and none."
Does cutting a golf shaft affect flex?
Cutting Golf Shafts and the Effect on Flex. All golf shafts taper; that is, their circumference is greater at the grip end than at the tip end. That means that the grip end is the strongest part of the shaft and the tip end the weakest, which, Wishon says, leads trimming to have different effects: "Cutting more of the tip will have the effect ...
