How many volts does an EZ GO golf cart use?
The electrical drive system powered for EZGo golf carts is either 36-volt or 48-volt. Some newer models are 72 volts. This requires a combination of multiple batteries in other to work properly.
Do all EZGO golf carts have a serial number?
Sometimes previous owners rip them off, change out parts or paint over for whatever reason. Basically on ALL Ezgo golf carts from 1980 and up will have a 4 digit manufacture date code and a 6 digit serial number.
How many CC’S does an EZGO have?
In between then they developed another great little engine which was Ezgo’s first four stroke. It was a 9 hp – 295 cc engine that just performed great and was used in all Marathon models.
How many volts is a golf cart battery?
48 Volt Golf Cart Example (12V Batteries): 6 holes X 2 volts = 12 volt battery. 12 volt battery X 4 total batteries = 48 volt system. If you have additional questions about your batteries or charger, check out our Battery Charger Frequently Asked Questions page.
What voltage is my ezgo cart?
The standard electric golf cart will have four, six, or eight batteries in total. The voltage will be either 36 volts or 48 volts. These batteries will be contained in a single system, that looks a bit like a large block/box.
What year did ezgo go to 48 volts?
2008EZGO - EZ-GO introduced their 48V system in 2008. Yamaha - Yamaha introduced their 48V system in 1995.
Is my golf cart 36 or 48 volt?
Determining how many volts your golf cart uses is as easy as counting the water fill caps on all of your batteries. If you have six 6 volt batteries your golf cart is a 36 volt cart, if you have six 8 volt batteries or four 12 volt batteries your golf cart is a 48 volt cart.
How do I know what voltage my golf cart battery is?
Lift up the seat to view the battery compartment. Count the number of holes on each battery. You may need to remove the battery cap to see the holes. Multiply the number of holes by 2 to determine the golf cart battery voltage.
Can I run 48V on a 36V golf cart?
It all depends on your battery bank used with this 36V to 48V conversion. can only be accomplished through installing a 48V motor capable of higher torque, or installing a 48V controller with a higher current limit (amperage).
What is a 72 volt golf cart?
0:562:59E Z GO 72 volt Performance 2018 - YouTubeYouTubeStart of suggested clipEnd of suggested clipThe 72 volt powertrain includes six 12-volt batteries and a 350 amp controller these models utilizeMoreThe 72 volt powertrain includes six 12-volt batteries and a 350 amp controller these models utilize AC. Drive technology that is up to 25 percent more energy efficient. Than the DC. Technology.
How many volts should a 36V golf cart have?
For example: a 36v battery pack will read 38.2v fully charged. Maximum drop under load should not be more than 6v below 38.2v equal to 32 volts or less.
What should the voltage be on a fully charged 36V golf cart?
The target voltage for a 36 volt charger for AGM or some flooded batteries is 2.4 to 2.45 volts per cell, which is 43.2 to 44.1 volts.
How do you check the voltage on a 36 volt golf cart?
0:296:18How to Test Golf Cart Batteries - Troubleshooting Batteries - YouTubeYouTubeStart of suggested clipEnd of suggested clipThe battery voltage can be buy tested by probing with a simple voltmeter by pushing the probesMoreThe battery voltage can be buy tested by probing with a simple voltmeter by pushing the probes deeply into the lead not in not into the stainless steel put into the lead.
How many volts should a 48 volt golf cart have?
The target voltage for a 48 volt charger for AGM or some flooded batteries is 2.4 to 2.45 volts per cell, which is 57.6 to 58.8 volts.
How many amps does a 12-volt golf cart battery have?
6 vs 8 vs 12-Volt Golf Cart Batteries – Runtime at 56 Amps The average runtime minutes at 56 amps was 164 for the 6-volt batteries. 8-volt batteries averaged 128 minutes of runtime. While the 12-volt options clocked 110 minutes of runtime.
How many batteries does a ezgo golf cart take?
Get the right batteries The EZGO Medalist and Txt carts are based on a 36 volt battery bank. Consisting of six 6 volt golf cart batteries.
How many volts does a golf cart have?
There is a major difference between 36 volt up to 48 volt systems, impacting both performance and potential upkeep and maintenance costs. Hint: some batteries are much more expensive ...
What is the amperage of a golf cart?
Golf Cart Battery Amps. Amperage can be considered akin to the fuel in a gas-powered engine. Similar to a tank of gas, the amount of amperage will dictate how far you can drive your cart on a single electric charge.
What does voltage mean in a battery pack?
Voltage represents how much power your system will be delivered, resulting in increased ability to tow, carry more weight, and accelerate faster.
Does a golf cart battery need to be recharged?
In this regard, a higher voltage (although more powerful) often comes at a cost. That cost is that it can burn through more amps faster, draining the golf cart battery quicker, and requiring you to recharge more frequently.
How many volts does an EZGo golf cart use?
This is so a steady current can be achieved for miles. The electrical drive system powered for EZGo golf carts is either 36-volt or 48-volt. Some newer models are 72 volts.
What is the voltage of a golf cart?
The most common voltage in golf carts today is 48 volt s. Some older models are 36 volts, and some newer are 72 volts. 48 volt carts can either have 4 12v batteries, or six 8 volt batteries. A 36 Volt Pack is seen on most older golf carts and has a series arrangement of six 6 Volt batteries.
How to figure out the voltage of a golf cart battery?
For each battery, the total number is typically 3, 4, or 6 holes on the top. To figure out the golf cart battery’s voltage, for each of the number of acid holes on one of your batteries , multiply the number by 2. Each hole is equal to 2 volts. Finally, multiply the voltage of the golf cart battery by the sum of the golf cart batteries ...
How to tell what kind of battery is in a golf cart?
The fastest way to know the kind of batteries your golf cart houses is the following: Pull your golf cart’s front seat upwards and identify the location of the golf cart battery compartment. Look for markings that tell you the battery’s voltage. If there are no markings, continue to step 3.
How many volts does a golf cart battery have?
For most of the electric golf carts, it is never a surprise that they are common with this 6-8 volt golf cart battery pack configuration.
How does a golf cart work?
The operation of golf carts effectively takes place on a series of golf cart batteries to supply enough power. That is, the battery system is a series, hence more than one battery connected together to multiply the voltage.
How many batteries are needed for a 36 volt golf cart?
Only in older 36-volt carts, you’ll find 3 batteries, and some 6-volt versions will have 8 batteries. In the golf cart design, the (multiple) batteries altogether supply the right amount of voltage and amperage required to power the cart. That is, when this 3, 4, or 6 batteries are linked, they will sum up and produce a power ...
Where is the serial number on an EZGO TXT?
Serial Number located on a plate located inside the passenger side glove compartment. EZGO TXT made in the years 1996 - Present will look like the golf cart pictured above. Serial Number located on a plate inside the passenger side glove compartment.
What years were the Ezgo Marathon made?
EZGO Marathon made in the years 1979 - 1994 will look like the golf cart pictured above. Two separate seat backs. Plastic front bumper. No Top Handles. The model and serial numbers can be found on the plate located under the passenger side glove compartment.
When did Ezgo golf carts start being battery powered?
All Ezgo golf carts where battery powered until 1971 when they introduced the first gas engine sourced from Fuji. To date they have produced millions of Gas or Electric vehicles most of which still in service today throughout the world.
When was the first Ezgo golf cart made?
The first gas model Ezgo golf cart was produced in 1971. 1971 was great year for a lot of things with gas combustible engines. Ezgo was no exception. This was a milestone for them as it stood up until then all were strictly electric vehicles. Using a 175cc model 17-CES 1PG two cycle Robin version.
When was the Ezgo Marathon Golf Cart made?
The Ezgo Marathon Model Golf Cart (1975 -1993 ) With great success and production numbers thus far for the company, the introduction of the Marathon model golf cart was bringing in a whole new era of golf carts and technology.
When did Billy and Ezgo leave Ezgo?
In the 1960’s they sold out to current owners Textron Company. The two brothers continued to work with Ezgo and Textron until 1978. Then Billy and a handful of employees decided to leave Ezgo to purchase Club Car at the time was located in Texas.
When did Ezgo use the EC25?
The EC25-2PG engine model was used until 1988. Then in 1989 they used the EC25-3PG 244cc two stroke Robin engine model but only until 1993. In between then they developed another great little engine which was Ezgo’s first four stroke.
What engine did the EC25-DS have?
In 1976 they came out with a six head bolt model EC25-DS 244cc two stroke Robin engine also made by Fugi. This engine also had an internal starter/generator.
When did Ezgo carts start running on batteries?
EzGo Models And The Years Produced. All of the carts produced ran on batteries until the year 1971 , after which the 175cc model 17-CES 1PG two-cycle Robin version was included in the options. From 1975 the EC25-DS 244c Robin engine was introduced.
What year was the 1974 Ezgo Classic built?
So, in our example serial number, we can tell this is a 1974 Three Wheel EzGo Classic (Marathon started in 1979) that was built in the 6th month of production and was the 3,456 unit off the line. If the serial had been 6444 3456, then it would have been a 4 wheel golf cart.
What is a golf cart?
Golf carts are also known as golf cars. The term "cart", in its purest sense, refers to a vehicle that does not travel under its own power. Golf cars, however, are most commonly referred to as golf... link to Club Car DS Wiring Diagrams 1981 To 2002.
Where is the serial number on an EZGO?
Here are some of the earlier years: Before ’76, you could find the Serial Number Plates located under the driver side seat, just behind the driver side battery, on the fender skirt. Example manufacturing code 644X 3456.
Does every golf cart have a tagging standard?
Every golf cart manufacturer has its own tagging standard, and it’s handy to have a lookup table to sort out the makes and models. We will continue to keep these references up to date as we get more data and will keep the notes here for reference.
Do E-Z-Go Golf Carts have titles?
E-Z-Go Golf Carts, unlike vehicles, do not have a title, but they do have serial numbers. If you are buying a golf cart, it is essential to check the serial number to ensure you do not buy a stolen one. Each E-Z-Go Golf cart has a unique serial number that you can use to identify your golf cart.
Where is the E-Z-Go Cart Serial Number
As mentioned above, all E-Z-Go Golf carts have unique serial numbers. These numbers are essential when buying replacement parts for your golf cart. Textron Specialized Vehicles has been building golf carts for a long time, and the serial numbers are placed on different parts of the golf carts.
How do I push my E-Z-Go Golf Cart?
It can be frustrating when your battery is flat and your golf cart will not roll. To push it to the nearest charging or gas station, you need to release the motor brake. Follow these easy steps to do that.
Why does my E-Z-Go golf cart not move
There are several reasons why your cart refuses to move, but you should check the battery before anything else. If the battery is charged, here are some other reasons why your golf cart will not move.
Are all E-Z-Go Golf carts electric?
No, there are both electric and gas-powered E-Z-Go Golf carts available. Bear in mind that there are several models you can drive on the street, but those are all-electric. These electric models run on batteries that you have to charge at least every 24 hours, depending on how much you use them.
How to tell the Assembly year of my E-Z-Go golf cart
The placement of serial numbers is discussed above, and you will find the manufacturer’s number right next to it. The manufacturer’s number consists of one letter and 3 or 4 numbers. The last two numbers indicate the last two digits of the year of assembly.
How to service E-Z-Go Golf Cart
Like all vehicles, E-Z-Go golf carts require regular maintenance to enhance longevity and performance. You should ensure that your golf cart is serviced after every six months of use. That will ensure that you spot problems and repair them early, which will help reduce repair costs. Here are essential guidelines for E-Z-Go golf cart maintenance.
1. What Does TXT Mean on EZGO Golf Carts?
The acronym ‘TXT’ found on EZGO golf carts stands for Textron, which is the company that is responsible for the manufacturing of the cart. Textron is a multi-industry company and as well as manufacturing EZGO carts, they support brands including Bell, Cessna, Beechcraft, and Lycoming.
2. How Much is an EZGO TXT Golf Cart?
For a new EZGO TXT golf cart, you can expect to pay between $8,000 and $9,000. For example, the new EZGO TXT Freedom is currently retailing at $8,399 directly from the EZGO online store.
3. What Years Did EZGO Make the TXT?
The first EZGO TXT golf cart was manufactured in 1996, and a new model has been released every year since. It is the current model of EZGO carts and one of the best-selling golf cart models of all time.
4. Is my EZGO a TXT or RXV?
The two most popular models of EZGO golf carts are the TXT and RXV, so which do you have? Well, the best way to look at it is that the TXT is EZGO’s standard, while the RXV is much easier to customize and enhance.
5. Is EZGO TXT a Good Golf Cart?
The EZGO TXT is one of the best golf carts available on the market. In production since 1996, it has been the cart of choice for many clubs and golfers alike and is admired for its longevity and ‘workhorse’ properties.
6. How Much Does an EZGO TXT Weigh?
The EZGO TXT has a dry weight of 557 lbs (253kg) without batteries. This table consists of some of the key specifications regarding the weight of the EZGO TXT, so you can ensure it is within your requirements before purchasing it.
7. How Do I Increase the Speed of My EZGO TXT?
On level ground, the EZGO TXT is capable of speeds between 10.2 – 14.8 mph (16.4 – 23.8 kph), but it’s possible to increase its speed if you know-how.
How many models are there in Ez Go?
E-Z-GO Golf Carts are broken down into eight base models. Four of these models, Marathon, Medalist, TXT, and RXV are the most common.
Where to find the serial number on a golf cart?
Serial & Manufacturer Number Location: Serial and manufacturer numbers can be found on a plate located in the glove box on the passenger's side of the vehicle. Serial numbers consist of 6 or 7 numbers and do NOT indicate the year the golf cart was manufactured.
