Full Answer
How much HP can a DSG handle?
The DSG can handle 600+nm once it has Tune to increase clamping. Its hard to know as most that building 500+HP cars have the common sense to do engine build and upgrade the DSG clutches to get most from their build reliably. My thoughts are stage 1/2 are fine with DSG tune.
What are the benefits of a performance DSG tune?
A performance DSG tune, even on stock programming, will usually result in noticeably improved power output and delivery characteristics. Since virtually every aspect of a DSG transmission is computer-controlled, a performance tune can also increase the effective power handling of the transmission tremendously.
What happens if you tune up a DSG transmission?
Since virtually every aspect of a DSG transmission is computer-controlled, a performance tune can also increase the effective power handling of the transmission tremendously. A stock TCU matched to a highly modified engine may result in slipping clutches or even clutch damage.
What are the torque specifications for the DSG transmission?
Important Torque Specifications For The DSG Transmission 1 Drain plug: 33 lb-ft (45 N m) (replace crush washer) 2 Spillover tube: 2 lb-ft (24 inch-pounds / 3 N m) 3 DSG oil filter cap: 15 lb-ft (20 N m) 4 CV Axle to output flange: 52 lb-ft (70 N m) (replace) More ...
How much torque can a Golf R DSG handle?
Yes it will be able to handle about 600Nm of torque without breaking but eventually clutch will start to slip on DQ250 units (used for GTI and R). So clutch will be the limiting factor on DSGs.
How much power can you get from a Golf R?
That's where the R makes the most power - 750 hp at the crank, but it may be even slightly more than that, apparently. Sam says he also runs a more relaxed configuration that drops pressure to 39 psi (2.7 bar) but still pushes out roughly 720 hp.
Is the 7 speed DSG better than the 6 speed?
0:303:03Are 7 Speed DSG as Reliable as 6 Speed DSG? | AskDap - YouTubeYouTubeStart of suggested clipEnd of suggested clipI don't feel like we have a good enough track record with them to say definitively the reliabilityMoreI don't feel like we have a good enough track record with them to say definitively the reliability of one versus the other I do expect the 7-speed to overall feel better.
Is the 7 speed DSG reliable?
Are DSG gearboxes reliable? DSG gearboxes have proven themselves to be very reliable both in six, and seven-speed variants. Failures occur rarely, but when they do they are likely to be expensive. These relatively uncommon faults are usually found in older higher-mileage vehicles.
How much HP does a Stage 2 Golf R make?
Unitronic Stage 2: 397HP / 368LB-FT.
How can I make my Golf R faster?
0:1111:10This EASY Mod Made My 2019 Golf R MUCH FASTER! - YouTubeYouTubeStart of suggested clipEnd of suggested clipYou want to give your car at least 20 minutes uh you know i would say like you're you have to haveMoreYou want to give your car at least 20 minutes uh you know i would say like you're you have to have the car in auxiliary mode. So you have to leave the car on for at most like 20 to 30.
Is the Golf R DSG reliable?
DSG is going to be more reliable, in general, than the manual. The DSG is arguably the most reliable, and perhaps the best performing twin-clutch on the market. The manual is the no-cost option with a zillion cheaper-out parts.
Is DSG as fun as manual?
While you can still have a lot of fun with a DSG GTI hitting some backroads, if you're not chasing lap times or really pushing the limits, it's a little less rewarding of an experience. Not to say you can't have fun; it's just not the same as rowing the gears in a manual GTI.
How long does a DSG last?
Maintained properly, the DSG box should last well over 150,000 miles without needing clutch replacements as it is a wet clutch system and much gentler on the clutches than a human driver.
Is VW DSG dry or wet clutch?
Apart from the number of forward gears, the DSG gearboxes are equipped with different types of clutch. The gearboxes designed for low torque values feature two dry clutches while the units designed for higher torque values are equipped with wet clutches running in a sump.
Is 7 speed DSG wet or dry?
The 6 speed DSG units are usually wet clutch and the 7 speed are dry.
How do you drive DSG in traffic?
How to use DSG transmission properly in traffic jamsIt is not recommended to set the gear selector to N position. ... Do not drive very short distances frequently alternating gas-brake pedals. ... Let the car in front drive at a distance of about 5 meters from your car and follow this car at a low speed in first gear.More items...•
How much HP does a Stage 3 Golf R make?
Matt is testing the new camouflage-clad creation from APR, dubbed the Stage 3+ "Gonzo" Golf R, which makes 470-horsepower at the wheels on premium gas and 536-wheel-horsepower on 104 octane racing fuel.
What is the WHP on a Golf R?
As a refresher, VW rates the new Golf R at 315 horsepower, which translates to 235 kilowatts and 320 metric horsepower....Gallery: 2022 Volkswagen Golf R.CategoryIndustryMake/ModelVolkswagen Golf RBody StyleHatchbackMar 19, 2021
How much horsepower does a VW Golf R have?
315 horsepowerUnderneath the hood of the new 2022 Volkswagen Golf R is a 2.0-liter turbocharged TSI® direct-injected four-cylinder engine that cranks out an incredible 315 horsepower and 295 lb-ft of torque.
How much power does a mk7 Golf R have?
The Golf R similarly had its output increased from 221 kW (296 hp; 300 PS) to 228 kW (306 hp; 310 PS).
What is Revo Is38ETR?
The Revo IS38ETR offers significant performance gains over a stock IS38. It comes with a new OEM compressor and turbine housings, so it’s a straight swap with no modifications needed. Every weak point of the stock IS38 has been enhanced. The compressor and turbine housings have been CNC re-profiled to match the larger wheels and stronger shaft. Strength is a key factor to the IS38ETR; a replacement back-plate machined from a billet piece offers greater resistance to warping. The larger bearing housing has also been upgraded to make room for a bespoke bearing system. Incorporating a reinforced thrust bearing. Precision balanced to levels above the OEM specification reduces vibration to the lowest possible level and improves the performance and reliability of the turbocharger. The IS38ETR is able to flow 40% more air than a stock IS38 unit.
What cars can fit the Gen3 EA888?
Including, the Golf Mk7 GTI, Audi S3 (8V), Audi TT / TTS (8S), SEAT Leon Cupra (5F), Skoda Octavia vRS (Mk3) and Skoda Superb 2.0 TSI. It’s been developed to install as a full drive-in drive-out package, which is available from any Revo Authorised Dealer.
Can a Gen3 2.0 TSI EA888 be tuned?
The Gen3 2.0 TSI EA888 unit responds so well to tuning. It’s now possible to create a big-power Golf R, without the need to open up the engine. The time and money savings make this a very attractive proposition. To find out just how easy it is to transform a stock Golf R into a 500bhp weapon.
Does the IS38ETR have an exhaust?
With the new turbo and air intake installed, it’s time to move on to the exhaust system. The IS38ETR turbo requires an uprated downpipe with a sports cat, plus a high-flow exhaust system. The owner of this Golf R has supplied a full turbo-back exhaust, which it has to be said looks stunning.
What is the DL800?
The DL800 is a 7-speed DCT transmission, utilized only in the Audi R8 and sister model from Lamborghini, the Huracan.
What transmission does Audi use?
Audi introduced the longitudinal DL501 7-speed S Tronic transmission in a variety of their more performance-minded sedans and CUVs such as the S4, S5, and S6. The DL501 differs from all of the transverse type DQ transmissions in that it has divorced lubrication systems. The oil for the gearing and differentials is separate from the oil, which is utilized by the clutches, Mechatronic unit, and pump. This should, in theory, provide longer life and more reliability as there is no cross-contamination of fluids or particles between the two separated sections.
What is a PDK transmission?
Porsche wins the award for the hardest to pronounce name with "Porsche-Doppelkupplungsgetriebe" (Porsche double-clutch transmission), which is what PDK actually stands for. PDK operates in the same fashion as all other dual-clutch transmissions but is known to be one of the most refined and best-performing DCTs on the market. Similar to VW and Audi designs, PDK transmissions are all transaxle designs. Porsche is notable for having developed a PDK transmission for racing use back in the early-1980s as part of their 956 / 962 Group C program. The PDK didn't prove to be reliable enough at the time but has since been used in a variety of the entry-level Cayman GT4 machines from Porsche. Similarly, Volkswagen DSG and Audi S Tronic are both used on factory-built race cars, including our own Volkswagen GTI TCRs.
How much torque does a DQ500 have?
With factory Mechatronic programming, the DQ500 is rated for up to 442 lb-ft of torque.
What does DSG mean in VW?
DSG stands for "Direkt-Schalt-Getriebe, " or direct-shift gearbox. The VW DSG transmission is similar to all other common DCT designs in that it is effectively two separate electronically controlled manual transmissions built into one. dsg-transmission-animation-4.
How much oil does a transverse transmission need?
The transverse DQ250 requires somewhere between four and five liters of DCT oil to perform a transmission service. The larger longitudinal DL501 typically requires between seven and eight liters of DCT fluid.
How fast does a DSG shift?
A DSG transmission can perform a complete shift in around 200 milliseconds and can shift more quickly than the best drivers in a similar manual transmission vehicle.
