Remove the screws and cover from the pedal box. Loosen the setscrew in cam using an 1/8" Allen wrench. Loosen the jam nut and move the cam to adjust as needed.
Full Answer
How do you tow an E-Z-GO golf cart?
Follow these easy steps to do that. Lift your E-Z-Go cart’s front seat. You will see the tow/run switch; turn it to tow instead of run. Look for wires labeled 1, 2, 3, 4 and ensure that wire 1 connects to wire2 and where wire3 connects to wire 4.
How do you adjust the shift cable on an EZ GO golf cart?
At times, the cable connecting the forward-reverse shift in the E-Z-GO golf cart may need adjustments that are a little tough to carry out without a proper manual or instructions. A golf cart shift cable adjustment is 1 3/8-inch from the washer and is to be made till the end of the threads.
How to test the EZGO electronic speed control-series drive system?
Testing of the EZGO ELECTRONIC SPEED CONTROL - SERIES Drive system. ALWAYS DISCONNECT THE NEGATIVE BATTERY CABLE BEFORE REMOVING CONTROLLER COVER. RE-CONNECT CABLE AFTER COVER IS REMOVED. These tests are to be conducted after making sure all wires and cable connections are clean and tight.
Why is my E-Z-GO golf cart not running at a constant speed?
If you notice that your E-Z-Go golf cart is not running at a constant speed, you should troubleshoot the controller to identify the problem. Here are the steps you should use to test your E-Z-Go golf cart controller. Turn the maintenance switch under the switch to Tow-maintenance mode.
What does PDS stand for on EZGO?
The Precision Drive System (hereafter called PDS), was introduced by E-Z-GO in 2000.
How do you test a EZGO pedal sensor?
Take a digital multimeter and set it to the volts reading. Place the positive probe of the meter on the white wire terminal of the ITS. Release the accelerator pedal slowly. The reading should be in the 0.45V to 0.53V range when the micro-switch gets activated.
How do I adjust my EZGO speed controller?
Tighten the governor spring located in the engine of most golf carts to adjust your cart's top speed. 90% of EZ Go Carts have simple springs which limit the speed of the engine. To raise the top speed of your golf cart, all you need to do is locate this spring and tighten it slightly.
How do you adjust the throttle on a EZGO TXT golf cart?
EZGO TXT throttle adjustment Tighten the other nut that is before the bracket making sure that the throttle plate continues to be closed. Press the accelerator and listen for the clicking sound of the accelerator microswitch. The throttle plate should have moved only very little after the clicking action.
How do I test my EZGO PDS controller?
Check Power Output From the Controller Connect the negative probe to the controller's M terminal and positive probe to the B+ terminal. Press the accelerator and watch to see if the voltage increases. It should increase from a reading of 0 to the full voltage of the battery.
How do I know if my golf cart controller is bad?
X Common Symptoms of Controller FailureTop Speeds Not Appropriate for Your Cart. Golf carts are designed to reach pretty specific speeds and to not go over them or beneath them. ... Sudden and Unexpected Slowing. ... Shuttering or Shaky Driving. ... Stalling Out and Refusing to Start. ... Surges in Speed When Driving.
How do you adjust a speed controller on a golf cart?
Basically, an electric speed governor can be controlled by a tiny metal rod that's located by the clutch of your golf cart. First things first: The electric speed governor is connected to a cable. You can adjust your speed by rotating the nut in a counterclockwise rotation.
Where is the speed controller on an EZGO golf cart?
These speed controllers are located under the EZGO cart seat. Check the speed controller's attachment near the carburetor.
How do you make an EZGO golf cart go faster?
One way to increase the speed of EZ Go golf carts is to incorporate an octane booster when you fill the tank. The cart will have more pick-up, and it could gain as much as 5 mph. A different approach is to take out the throttle linkage governor on the carburetor.
How do you change the speed on a ezgo gas golf cart?
1:467:10Simple Adjusting of an E Z Go Golf Cart Governor - YouTubeYouTubeStart of suggested clipEnd of suggested clipFor follow the thickest table coming from the gas pedal until you find a small spring wrapped aroundMoreFor follow the thickest table coming from the gas pedal until you find a small spring wrapped around a metal rod.
How fast can a golf cart go without a governor?
What is the Average Golf Cart Speed? The average top speed of a typical golf cart without any upgrades is between 12 and 14 miles per hour. Without any sort of modification or upgrade on a golf cart, the top speed that you will be getting on a golf cart is about 14mph.
Why is my gas golf cart running slow?
Low Battery Usually, the most common reason golf carts slow down is when they don't get enough power output from the battery. If the battery pack charge is very low and your cart is out of power, your cart will run slow.
How does a golf cart speed sensor work?
Magnetic Style Many golf cart motor speed sensors employ an electromagnetic power to “read” the motor rpm. Generally, there is a magnet present in the closed end of the motor as well as the sensor itself which reads how the magnet is reacting with the magnetic field inside the motor.
What causes golf cart hesitation?
In most cases, the hesitation problem occurs due to bad batteries. If you have bought new batteries for your EZGO RXV, make sure to fully charge them before the first use. Batteries should then be charged after every use. To keep the batteries in check, get a Digital MultiMeter to measure the individual voltage.
What does a potentiometer do on a golf cart?
It sends an electrical signal to the speed controller from the accelerator pedal, indicating the pedal's position. When it is working properly, the potentiometer allows your golf cart to accelerate smoothly. Find your potentiometer and inspect it for any cracks, broken parts, or disconnected wires.
How do you troubleshoot an EZ Go golf cart?
Things to Keep in Mind Before TroubleshootingEZGO golf cart batteries aren't perfect right away.Sticky accelerators are perfectly normal and can be fixed easily.Keep your cart stable.Make sure your charging wall socket isn't faulty.Keep your tire pressure stable.Troubleshooting the speed controller.
What happens if you don't adjust your golf cart?
If there's no adjustment left the cable must be stretched. As long as you're getting full throttle and the golf cart is running fine at slower speeds I wouldn't worry about it.
Does the butterfly carburetor need to be adjusted?
No it sounds like the cable needs to be adjusted. The carburetor butterfly should start to open right after the micro switch activates and should close just before the micro switch clicks.
How to adjust a golf cart?
If you are only making an adjustment to the shift cable, follow these steps: 1 Examine the shift cable closely for any damage. 2 If it is damaged you must go for a full replacement. 3 Do this inspection when the golf cart’s engine is off. 4 Allow the engine to cool before you do this exercise. 5 The adjustment has to be done at both ends. 6 One is the transaxle end and the other end is where you use the handle to shift R and F. 7 You should thoroughly clean the cable using a spray like WD40. 8 You can do the shift cable adjustment, with the shift lever in the forward position and then again changing it to the reverse position. This has been seen to be the better method in the Yamaha G2
How far is the shift cable on a golf cart?
A golf cart shift cable adjustment is 1 3/8-inch from the washer and is to be made till the end of the threads. The adjuster has to be in the neutral position while making this change in the cable’s position.
How to adjust shift cable on Yamaha G20?
You can adjust the shift cable in the Yamaha G20 Gas by removing the adjustment nuts by slackening the jam nuts. Get the cables out by moving the shift lever back and forth. Now replace the cable and keep adjusting the cable-ending position at the transaxle end. They have to be of equal length.
What is a Project X HZRDUS shaft?
What is the Project X HZRDUS Black Fairway Wood shaft? Project X HZRDUS Black Fairway Wood shaft is a low spin golf shaft design. It comes with enhanced firmness over the entire length of the shaft....
Why do you need to mark the location of the bracket on the vehicle before pulling it out?
This helps to ensure that the replacement does not alter the arrangement in the area.
Can you replace the shift cable on a Yamaha G2?
You have to access the transaxle on the rear of the cart and pull out the bracket where the cables are attached. You can now replace the cable. Remember to mark the location of the bracket on the vehicle before pulling it out.
How to Adjust Brakes on EZ-Go Golf Cart?
Today we will discuss how one can adjust the brakes on an EZ-GO golf cart.
Why are golf carts so slow?
Because these vehicles are made to reduce the effort of the golfers and safely take the golfers to their suitable area. For their slow speed, there is no risk of major accidents.
Why does my golf cart get overturned?
Sometimes it seems that on these slope areas cart drivers are not able to stop the cart properly and the cart gets overturned. This happens because of over speed and the failure of the brake's ability. It can cause serious injuries to the driver and also to the golfers. Therefore proper adjustment of the breaks is needed.
Do golf carts need a break?
Different manufacturers use different mechanisms to make their golf carts. Some golf carts have their auto adjustable brake mechanism. These types of carts do not need their break to be adjusted.
Is an electric golf cart faster than a gas golf cart?
Generally, electric golf carts are slower than gas powered golf carts. But sometimes it seems that the EZGO golf carts are far slower than before. There are many reasons for it. Here are some reasons that will reduce the speed of the EZ-GO golf cart.
How do I push my E-Z-Go Golf Cart?
It can be frustrating when your battery is flat and your golf cart will not roll. To push it to the nearest charging or gas station, you need to release the motor brake. Follow these easy steps to do that.
How do you test an E-Z-Go Golf Cart Controller?
Depending on the E-Z-Go Golf cart you own, there are two types of controllers, the Drive control systems and the Precision Drive System. Only E-Z-Go carts made before 1994 have a Drive Control System. If you notice that your E-Z-Go golf cart is not running at a constant speed, you should troubleshoot the controller to identify the problem. Here are the steps you should use to test your E-Z-Go golf cart controller.
Why does my E-Z-Go Golf Cart feel sluggish when accelerating?
The reason why your golf cart is sluggish during acceleration or stalls depends on whether it is a gas cart or an electric one. Here are the reasons for sluggishness in both.
Why is my E-Z-Go golf cart losing power?
E-Z-Go golf carts often lose power because of corrosion or loose cables. If the connecting wires in electrical circuits break, your battery will lose power. The same will happen if you have a short circuit in the ignition system. Here are steps you can use to ensure that the system is working correctly.
Why won’t my gas golf cart charge the battery?
If you own a gas E-Z-Go golf cart, the battery may not get charged. Make sure that you have refueled your golf cart, and then check for the following issues.
Why does my golf cart stop moving?
This Golf cart is very temperamental, and even things like over-tightening a stud can make it stop moving. Check the F/R switch stud for overtightening. If it is over-tightened, the contact will not connect with the switch. Adjust this, and your golf cart will start working.
Why won't my golf cart start?
If your golf cart does not start even though the starter is rotating, there could be a problem with your battery, solenoid, or starter. Check the ignition and make sure you make the necessary repairs and replacements.
How does a pedal box work?
Basically, when you press down on the pedal, a metal rod is inserted into the sensor coil in the pedal box, changing the inductance of the coil, which reduces the voltage signal sent through it . This varying voltage signal tells the controller how much current the driver wants passed to the motor.
Why do no go carts have to be up off the floor?
Anytime you are testing a no go cart it must be up off the floor in the rear because it may start unexpectedly while testing which may cause body and property damage.
What is the purpose of having the solenoid engaged?
The purpose of having the solenoid engaged is to send current through the solenoid mains from battery B+ to controller B+.
Can you disconnect a switch with a multimeter?
With the multi-meter set to continuity or ohms you can disconnect both sides of the switch and connect it to the meter. The meter will show the connection making and breaking. If not check meter settings and test a different switch. Once you are certain your test method is correct retest the switch in question.
