How To Cut A Graphite Golf Shaft?

• Step 1: Prepare tools. Preparing your tools is the first step but will contribute to your success. If you prepare...
• Step 2: Measure and mark. Measuring and marking will help you know exactly where to cut and make them more specific. It...
• Step 3: Prepare to cut. After you have determined the point you want to cut, do not rush to pick up...

Full Answer

How to cut golf club graphite shafts manually?

One solution to manually cut golf club graphite (or composite) shafts fast, safe and efficiently is the rod saw blade . Let me give you some handy tips on how to use tool properly. Graphite shafts need special care to be cut properly.

How do you fix a loose grip on a golf club?

To do that, the DIY golfer will have to: Remove the existing grip. With steel shafts, use a tubing cutter to trim the shaft; with graphite shafts, shorten using a hacksaw. Re-install a grip on the newly shortened shaft. And, most importantly, Wishon says, add weight to the clubhead in some manner to restore the swingweight feel of the club.

Why do golfers cut the shafts on their clubs?

They do this to make their clubs better fit their swing, which might mean cutting the shaft simply to change length, or to change swingweight, flex or other playing characteristics. What effect does trimming the shaft have on a golf club?

How do you fix a bent shaft on a golf club?

Remove the existing grip. With steel shafts, use a tubing cutter to trim the shaft; with graphite shafts, shorten using a hacksaw. Re-install a grip on the newly shortened shaft. And, most importantly, Wishon says, add weight to the clubhead in some manner to restore the swingweight feel of the club.

How much can you cut off a golf shaft?

If you are going to shorten a golf club, there are a few things to keep in mind. The more shaft you cut off, the lighter, more stiff, and effectively flatter the club becomes. For every 1/2 inch you remove, you will lose approximately three swingweight points.

Can you cut your own golf shafts?

To do that, the DIY golfer will have to: Remove the existing grip. With steel shafts, use a tubing cutter to trim the shaft; with graphite shafts, shorten using a hacksaw. Re-install a grip on the newly shortened shaft.

How do you cut a golf shaft at home?

1:2914:05Golf Club Repair - How To cut a Golf Shaft - YouTubeYouTubeStart of suggested clipEnd of suggested clipIf you're gonna if this is going to be your primary cutting tool don't skimp alright I'm a big toolMoreIf you're gonna if this is going to be your primary cutting tool don't skimp alright I'm a big tool nut don't skimp even if it's a hand tool.

How do you cut a golf shaft length?

0:483:03Golf Tips : How to Trim Golf Club Shafts - YouTubeYouTubeStart of suggested clipEnd of suggested clipFirst thing we got to do is determine the length of the golf club we're going to we're going to cutMoreFirst thing we got to do is determine the length of the golf club we're going to we're going to cut and how much we need to cut off of it. So we're going to lay the club.

Is it OK to shorten a driver shaft?

Shortening the shaft will make the club shorter but it will also make the shaft stiffer and adjust the swing weight as well. Plus, the more length you remove, the less flex your club will have. Depending on how much you cut it down, it could move a regular flex to a stiff or a stiff to an extra stiff.

Can you cut a graphite golf shaft with a hacksaw?

Yes, it is even strong enough to cut steel. It can cut through a graphite shaft in 15-20 seconds after the shaft has been securely place in your vise. The model we sell fits on a standard 12” hacksaw frame found at any hardware store or in many home shops.

How do you shorten driver shaft length?

1:144:01How to Cut Golf Shaft DIY - YouTubeYouTubeStart of suggested clipEnd of suggested clipSo for the first step you have to remove your old grip. I find the easiest way to do this is toMoreSo for the first step you have to remove your old grip. I find the easiest way to do this is to literally just cut a line all the way down your club.

How do you cut a steel shaft?

3:569:35The Basics of Shaft Cutting 1 of 3 - YouTubeYouTubeStart of suggested clipEnd of suggested clipThat's going to fit your budget. Let's talk about the tubing cutter or pipe cutter. First it's a lowMoreThat's going to fit your budget. Let's talk about the tubing cutter or pipe cutter. First it's a low cost method. At least initially for cutting steel shafts. These are not designed to cut composite

Does cutting a golf shaft make it stiffer?

In most cases, tip trimming a shaft makes it meaningfully stiffer. It also increases torsional stiffness, known as “torque,” which is a shaft's resistance to twisting. On the other end of the shaft is the handle, which is also generally trimmed some amount when building a golf club.

How long should my driver shaft be for my height?

Driver Shaft Length Based Solely on HeightHeight (feet/inches)Driver Shaft Length5'4″-5'7″45.5″5'2″-5'4″45″5'0″-5'2″44.5″4'10”-5'0″44″6 more rows•May 9, 2021

How much does it cost to cut down a golf club?

How much does it cost to shorten golf clubs? On average, it will cost $3-5 per club plus the cost of a new grip to shorten your clubs. If you're looking to save your old grips, you won't have to pay for new grips, but you'll have to pay a save grip fee of around $10 per club.

How does cutting a shaft affect swing weight?

For every half inch of length added, the swingweight increases by three swingweight points. For every half inch of length removed, the swingweight decreases by three swingweight points.

Step 1: Prepare tools

Preparing your tools is the first step but will contribute to your success. If you prepare incorrectly or lack the tools, it will take time in the process.

Step 2: Measure and mark

Measuring and marking will help you know exactly where to cut and make them more specific. It is impossible to guarantee that you will be satisfied with the first measurement results.

Step 3: Prepare to cut

After you have determined the point you want to cut, do not rush to pick up the knife to cut it. It would help if you prepared a little more to make the cutting process more convenient and safe for yourself.

Step 4: Cut a graphite golf shaft

After a complicated preparation process, now you have come to the most critical step: cut a graphite golf shaft. However, you do not need to worry too much if you have carefully prepared the above steps.

Step 5: Check the cut

The process of cutting a graphite golf shaft is almost complete. Now you just need to double-check that the cut is exactly what you want, and you can use it.

Series Navigation

I know this might seem obvious, but be sure to measure and mark off the point at which you are cutting. Especially while tipping a shaft (you can’t undo this), it is important to have precise measurements. Use a sharpie to make your marks on the shaft. Here is a tutorial on how to measure golf clubs.

Series Navigation

Hey!! I'm Zach, the founder of The DIY Golfer. I created this site in 2015 while playing D1 collegiate golf to help myself understand the game of golf better and improve as a player. Fast forward a few years, and it has become much more than a journal.

Why use masking tape on graphite shafts?

Secondly, by wrapping tape around the shaft, reduces the likelihood that the shaft would splinter during the last moment of the cutting process.

Can a rod saw blade cut steel?

It makes thin straight cuts in all types of shaft materials used in golf. Yes, it is even strong enough to cut steel.

Can a hacksaw cut steel?

Yes, it is even strong enough to cut steel. It can cut through a graphite shaft in 15-20 seconds after the shaft has been securely place in your vise. The model we sell fits on a standard 12” hacksaw frame found at any hardware store or in many home shops. How To Tips. I would like to share a few how-to tips as well.

Can you cut graphite shafts?

Graphite shafts need special care to be cut properly. A tubing cutter, that you would use to manually cut a steel golf shaft, will crack or destroy a graphite shaft in no time at all. Don’t think about pulling the hacksaw from your tool chest either.

Why trim a shaft?

Why trim or cut a shaft at all? When the manufacturers make a shaft, they do so in mind that is could be used for a wide number of golfers and applications, so the manufacturer makes the shaft longer than it will most likely be used in the final golf club. The number one reason for making the shaft longer is to accommodate taller players so they ...

Why do you need to trim a parallel shaft?

This is required to offset the increasing heads weights as the clubs become shorter and maintain the flex the manufacturer designed into the shaft for a finished club.

What is a combination flex shaft?

These "combination flex" shafts are designed to reduce inventory by being able to create multiple flexes from a single shaft rather than produce two different shafts. Here are the most common ones below.

What does a trimming chart show?

It is also important to understand the trimming charts show how much (if any) to take off the tip end (the skinny part or where the head will be attached). The trimming charts will not tell you an amount to take off the butt end (the fat part where the grip is installed).

How to shorten a golf club shaft?

To do that, the DIY golfer will have to: 1 Remove the existing grip. 2 With steel shafts, use a tubing cutter to trim the shaft; with graphite shafts, shorten using a hacksaw. 3 Re-install a grip on the newly shortened shaft. 4 And, most importantly, Wishon says, add weight to the clubhead in some manner to restore the swingweight feel of the club. "If clubs are shortened and no weight is added back to the clubhead, the chances of the length reduction having the desired effect are somewhere between slim and none."

What is the difference between a golf shaft and a tip?

All golf shafts taper; that is, their circumference is greater at the grip end than at the tip end. That means that the grip end is the strongest part of the shaft and the tip end the weakest, which, Wishon says, leads trimming to have different effects: "Cutting more of the tip will have the effect of getting rid of some of the weaker end ...

Should the reduction in length be made from the grip end only?

"If the goal in making the clubs shorter in length is a desire to gain an improvement in accuracy, the reduction in length should be made from the grip end only ," Wishon said.

Step 1

Determine how much of the shaft’s tip you wish to trim. The graphite shaft will come with trimming instructions that tell you how much to cut from the tip, depending on the amount of flex you want. For example, you’ll trim more off the tip to achieve a stiffer flex.

Step 2

Place the shaft into a rubber golf club clamp, then insert the clamp into a vise. The rubber protects the graphite from damage.

Step 3

Wrap two or three layers of masking or electrical tape around the area to be cut. The tape helps prevent the shaft from splintering.

Step 4

Measure the distance that you wish to trim from the tip, then mark the distance on the tape with a pen.

Step 5

Cut carefully along the marked line with a hacksaw, insuring your blade is perpendicular to the shaft. The Clubmakers.co.kr site suggests using a grit edge blade in your saw.

Step 6

Determine how much length must be trimmed from the butt end of the club. This typically depends on the type of club you're constructing. For example, the standard length of a graphite men’s 5-iron is 38 inches, while a standard 9-iron is 36 inches long, according to the Clubmakers website.

Step 7

Tape and mark the area to be cut, as you did with the tip. However, add 1/8 inch to the cut to account for the grip cap. For example, if your 9-iron shaft is 38 inches long after trimming the tip, trim 2 1/8 inches from the butt end to produce a 36-inch club after the grip is installed.

Feedback

Hey guys. I want to cut a half inch off my driver shaft. I've done a lot of searching but am not finding a definitive answer. I know you need to wrap the area you're cutting in masking tape but what's not clear to me is the correct type of blade to use. Some say hacksaw, others say a chop saw (which I have to admit, I have no idea what that is).

Feedback

i've used a dremel -- or a chop saw. either work fine. hacksaws COULD splinter the ends --not sure if it's 100% true but, i'd rather not risk it.

Feedback

I used a miter box and hacksaw with a blade with the highest number of teeth per inch (TPI) I could find at the hardware store. Came out just fine.

Feedback

What is a chop saw? I have a dremel but what attachment should be used? Also, if using a dremel, how do you get the cut perfectly straight?

Feedback

I'll use anything that has fine sharp teeth. I've done most of my shafts by hand recently because I have limited space and its easier without needing electricity and cords.

Feedback

Dremel cutoff wheel. They use a similar abrasive material circular saw blade as a chop saws uses (which is what you will find at a club maker for cutting graphite shafts). I use it for my graphite shafts as well as my carbon fiber arrows for my compound bow. Never had problems with either.

Feedback

Chop saw is best, Dremel with cutoff wheel will work (but it is tough to make an even cut), and if you use a hacksaw get a 'grit' blade.
