- Lift up your golf cart seat to locate the battery compartment.
- Count the number of holes on a battery. ...
- Multiply the number of holes by 2 to determine the golf cart battery voltage. ...
- Multiply the golf cart battery voltage by the total number of golf cart batteries.
How do I know if I have a 36 volt or 48 volt golf cart?
Determining how many volts your golf cart uses is as easy as counting the water fill caps on all of your batteries. If you have six 6 volt batteries your golf cart is a 36 volt cart, if you have six 8 volt batteries or four 12 volt batteries your golf cart is a 48 volt cart.
How do you test a golf cart electric motor?
3:5410:28Testing 36 volt golf cart motor with 12 volt battery - YouTubeYouTubeStart of suggested clipEnd of suggested clipYou just want to connect the two together with this again a2 to s1 with this jumper cable. And youMoreYou just want to connect the two together with this again a2 to s1 with this jumper cable. And you want to take the battery box or positive cable and put it on the s2.
Can I change a 36V golf cart to 48V?
It all depends on your battery bank used with this 36V to 48V conversion. can only be accomplished through installing a 48V motor capable of higher torque, or installing a 48V controller with a higher current limit (amperage).
What is the difference between a 48 volt and 72 volt golf cart?
48-volts are a popular option as they are more affordable to maintain, and they deliver a moderate level of power. The 72-volt options are more powerful and can deliver accelerated speeds for longer. However, they require more battery packs than a 48-volt cart, increasing the upfront and maintenance costs.
How do I know if my electric golf cart motor is bad?
You have enough going on in your life without your golf car refusing to start when you turn the key in the ignition. If your golf car won't start, is slower than it used to be, or is experiencing other technical problems, you could have a bad motor on your hands.
How do you test a motor with a multimeter?
Set your multimeter to Ohms. Start by completely disconnecting the spindle motor from all power sources. Check each wire, including T1, T2, T3 and the ground wire. If the reading is infinite, your motor should be fine.
What happens if you put 48V to a 36V motor?
It won't hurt it to try it. All the will happen is that the controller will shut down earlier if the cut off voltage is set for the 48v which might be right at 42v which would be peak on the 36v.
What year did ezgo go to 48 volts?
2008EZGO - EZ-GO introduced their 48V system in 2008. Yamaha - Yamaha introduced their 48V system in 1995.
How can I make my 36V golf cart go faster?
6 Ways You Can Make a Golf Cart FasterAdd More Torque to Your Golf Cart.Upgrade Your Golf Cart's Motor.Improve the High-Speed Controller of the Cart.Add Better Golf Cart Tires.Use a Higher Powered Golf Cart Battery.Watch the Weight in Your Golf Cart.
What voltage is best for golf cart?
48 Volt Golf CartThey are easily converted into hunting buggies or offroad carts.They use 1/3 less amperage than 36 Volt carts, so they are more efficient.Parts, especially upgrades, are more readily available for 48 Volt systems.Golf carts with 48 Volt systems have higher resale values.
What voltages are golf carts?
The standard electric golf cart will have four, six, or eight batteries in total. The voltage will be either 36 volts or 48 volts. These batteries will be contained in a single system, that looks a bit like a large block/box.
How many volts should a 48 volt golf cart have?
The target voltage for a 48 volt charger for AGM or some flooded batteries is 2.4 to 2.45 volts per cell, which is 57.6 to 58.8 volts.
