The removal of the drive belt on a Club Car golf cart involves a series of steps as given below:
- Turn the Forward/Reverse handle to Neutral.
- Chock the wheels of the cart.
- Disconnect the battery by removing the negative cable first, followed by the positive.
- Disconnect the spark plug wire from the plug.
- It would be better to wear gloves when you do this.
How to replace a drive belt on a golf cart?
Stretch the belt over the front pulley. You will have to pull the front clutch pulley a little forward to create tension on the belt. Tighten the tension bolt using a wrench. Now your Club Car golf cart has a new drive belt and you will be able to feel the difference when you drive the cart around.
How do I know if my golf cart drive belt is bad?
The best test to see if a golf cart drive belt has the correct tension is to use the Finger Test. Press the drive belt with one finger at its center between the two clutches. It should sag by just an inch and a half. Another method suggested by an expert is to go for a drive belt that is 1-inch shorter than the stock belt in your cart.
What to do if your 1997 club car drive belt is slipping?
When a 1997 Club Car drive belt is slipping, first make sure that it is the drive belt that is at fault. You may have to remove the cover and watch the clutches in action while the cart is in motion to make sure that it is indeed the drive belt that is slipping. You will have to change the drive belt as there is no other alternative to it.
How to replace a clutch on a golf cart?
Switch OFF the golf cart’s engine. Take a screwdriver and gently insert it between the belt’s bottom and the clutch’s groove. Slowly rotate the clutch and the belt will come off easily. If the belt is already loose, taking it out is very easy.
How do you change the belt on a Club Car DS?
There is no provision for adjusting the drive belt on a Club Car golf cart. If you find the belt loose or too tight, you have to go for a replacement belt. Choosing the right belt and ordering can pose a challenge. You will need to order a drive belt that is 1-inch shorter than your stock belt.
How do you change a belt on a Yamaha golf cart?
0:563:28Yamaha Drive 2 Quietech G29 Drive Belt Replacement - YouTubeYouTubeStart of suggested clipEnd of suggested clipFirst and then you can remove it from the front clutch make sure that your cart is in neutral. SoMoreFirst and then you can remove it from the front clutch make sure that your cart is in neutral. So the cart can freewheel back and forth without turning the clutch.
How tight should a golf cart drive belt be?
The drive belt should not be too tight. If it's too tight it can risk wearing off faster and it's also harder to shift gears. To check if your drive belt is set just right make sure your golf cart is turned off then check the drive belt by pressing it down between the two clutches with your finger.
How do you tighten the belt on a EZGO golf cart?
And EZGO is no different – there are no screws, knobs, or any other type of adjustment item that you can use to tighten up your belt. Once the belt is one, it has the same tightness and can only be changed if you swap the belt for another one either the proper length and width for your specific cart engine.
How do you change a drive belt on a Yamaha g16 golf cart?
0:352:32HOW TO CHANGE A DRIVE BELT ON YAMAHA GOLF CART ... - YouTubeYouTubeStart of suggested clipEnd of suggested clipJust put the lever in front halfway from reverse and forward. Once it's in reverse and you can spinMoreJust put the lever in front halfway from reverse and forward. Once it's in reverse and you can spin the back off.
How do I know if my golf cart belt is bad?
0:152:00How to Check the Belts in your Gas Golf Cart | Golf Cars UnlimitedYouTubeStart of suggested clipEnd of suggested clipDown below and you don't want to press the moderate pressure on that belt you're gonna want to seeMoreDown below and you don't want to press the moderate pressure on that belt you're gonna want to see about 3/16 to 1/4 inch of deflection. There no more than that that'll be your proper.
How can I speed up my Club Car golf cart?
0:061:31Club Car Precedent Speed Increase SUPER EASY!!! - YouTubeYouTubeStart of suggested clipEnd of suggested clipIf you turn it that way to the right or what appears to be counterclockwise. It slows it down. AndMoreIf you turn it that way to the right or what appears to be counterclockwise. It slows it down. And if you turn it that way or clockwise it speeds things up. Very.
How do I stop my golf cart belt from squeaking?
Your belt may also be wearing down and even fraying which is a problem that can cause the belt to both squeak and whine as it runs. Replace any frayed belts right away, before they break, to avoid damaging your engine, and lubricate or replace any pulleys which continue to squeak on your cart.
Can you adjust a golf cart clutch?
If you are unsure about removing the drive belt or the clutch, then you can adjust it. Just take out the belt and wound it again with the secondary clutch according to the requirements, and your problem should be fixed.
Are golf carts belt driven?
Belts - Drive Belts The drive belt on your club car golf cart is the one that is loose between both your drive and driven clutch. A worn out belt will slip and not allow your carts engine to power your rear wheels. Replacing your belt will give your golf car a smoother take off and increase the torque as well as speed.
How does a golf cart clutch work?
Both golf cart clutches look similar to a large pulley but each clutch has a sliding sheave that moves in & out along a central shaft as the clutch spins. The other sheave is fixed to either the crankshaft or the differential input shaft and it does not slide, it just spins.
Do golf carts have transmissions?
All golf carts (much like cars) have a clutch, which is the part of the drivetrain that helps the put the power of the motor down through to the wheels/ground. Golf cart clutches are a part of the Continuously Variable Transmission (or CVT).
How to change the belt on a golf cart?
Slide the old drive belt off the front drive clutch pulley, and then the rear clutch pulley. Slip the new belt around the golf cart's clutch pulley, and then stretch it out over the front pulley. Pull the front pulley forward slightly to increase the belt tension, and then tighten the tension bolt with the wrench.
Why does my golf cart not engage?
If the cart is having trouble accelerating or will not engage at all, it may be because the belt needs changing. Park the golf cart, and turn off the engine.
How to check if golf cart drive belt is too tight?
To check if the drive belt is too tight, follow these steps: Switch OFF the golf cart ’s engine. Reach to where the drive belt is located and use your fingers to press the drive belt between the two clutches. The belt must deflect at least one and a half inches under the pressure of your fingers.
What happens if a golf cart belt is too tight?
If the belt is too tight then your starter will be under strain and this should be avoided. The best test to see if a golf cart drive belt has the correct tension is to use the Finger Test.
How to tell if a 1997 club car has a slipping drive belt?
When a 1997 Club Car drive belt is slipping, first make sure that it is the drive belt that is at fault. You may have to remove the cover and watch the clutches in action while the cart is in motion to make sure that it is indeed the drive belt that is slipping.
How to remove drive belt?
Removing the drive belt involves holding the belt with both hands in the center between the driven and drive clutches and lifting the belt. You must now rotate the driven clutch counter-clockwise and slip the belt off the sheave. You can then slide the drive belt off the drive clutch.
Why is my club car drive belt so tight?
The reason for a Club Car drive belt being too tight can be because the drive belt is too small for the golf cart. The way to check if the belt is fitted correctly is to push the belt down with one finger at the center between the clutches. It should not deflect more than 1.5inches. It should not be less as well.
What is the primary function of a golf cart drive belt?
To primary function of a golf cart drive belt is to connect the primary clutch and the secondary clutch. The primary clutch drives the cart and the belt helps it to rotate the secondary clutch (they are referred to as the drive clutch and the driven clutch respectively). The drive belt, unlike some of the other automotive belts, are very thick.
Why does my golf cart drive belt slip?
The reason for the drive belt slipping could be that it is of a larger/longer size and therefore loose. You may start feeling the slippage after driving for a while. This is because the belt gets heated up after the golf cart runs for some time and loosens further .
