Remove the floor cover and pedal inspection cover.Disconnect the brake linkage, wiring and removethe four pedal assembly bolts. Turn the assemblyupside down and place the new switch mountingbracket in place. Mark the bracket mounting holesfor alignment with the switch lever arm makingclosed contact with the pedal ridge. Use a 3/32" drillbit as a pilot hole for screw installation.
