The best test to see if a golf cart drive belt has the correct tension is to use the Finger Test. Press the drive belt with one finger at its center between the two clutches. It should sag by just an inch and a half.
How do you measure a drive belt for a golf cart?
0:002:04Cover. Now the first measurement we're going to take on this is we're going to measure from theMoreCover. Now the first measurement we're going to take on this is we're going to measure from the centerline of the crankshaft. To the centerline of the jack shaft.
How wide is a Yamaha golf cart belt?
1-3/16″ wideBelt size is 1-3/16″ wide x 39″ long.
How tight should a golf cart drive belt be?
The reason for a Club Car drive belt being too tight can be because the drive belt is too small for the golf cart. The way to check if the belt is fitted correctly is to push the belt down with one finger at the center between the clutches. It should not deflect more than 1.5inches.
How do you measure a CVT belt?
0:321:30There are three numbers to be aware of they're usually printed on the side of the belt hitch lengthMoreThere are three numbers to be aware of they're usually printed on the side of the belt hitch length the width of the belt. And the angle of the teeth.
How do you change a drive belt on a Yamaha golf cart?
0:462:46Now to wet do this on the back clutch or the secondary clutch take the belt and slowly lay it overMoreNow to wet do this on the back clutch or the secondary clutch take the belt and slowly lay it over the top of this outer chief like this just slowly roll it over. And. It will come right.
Can you tighten a belt on a golf cart?
And EZGO is no different – there are no screws, knobs, or any other type of adjustment item that you can use to tighten up your belt. Once the belt is one, it has the same tightness and can only be changed if you swap the belt for another one either the proper length and width for your specific cart engine.
How do I know if my golf cart belt is worn out?
0:152:00And you'll have a symptom like a delayed start or something like that so 3/16 to 1/4 of an inchMoreAnd you'll have a symptom like a delayed start or something like that so 3/16 to 1/4 of an inch deflection on the starter belt on your drive belt. If you look in here in your drive belt.
How do I determine my belt size?
An easy way to determine belt size is to simply “add 2″ to your off-the-rack trouser size. For example, if you wear a 36” waist trouser, then a 38 belt size will be a safe bet.
How do you know what size pulley belt to get?
Lay the string flat and measure the distance between the end and the mark. Place the string on a flat, even surface and stretch it out so it's straight and taut. Use a ruler or tape measure to measure the distance from the end of the string to the marking you made to find the size of the pulley belt.
How do you measure a variator belt?
Measure the upper width of the belt, e.g. 47 mm = profile width 47 mm. Measure the belt thickness, e.g. 13 mm = profile 47 × 13.
How to check if golf cart drive belt is too tight?
To check if the drive belt is too tight, follow these steps: Switch OFF the golf cart ’s engine. Reach to where the drive belt is located and use your fingers to press the drive belt between the two clutches. The belt must deflect at least one and a half inches under the pressure of your fingers.
What is the primary function of a golf cart drive belt?
To primary function of a golf cart drive belt is to connect the primary clutch and the secondary clutch. The primary clutch drives the cart and the belt helps it to rotate the secondary clutch (they are referred to as the drive clutch and the driven clutch respectively). The drive belt, unlike some of the other automotive belts, are very thick.
How to tell if a 1997 club car has a slipping drive belt?
When a 1997 Club Car drive belt is slipping, first make sure that it is the drive belt that is at fault. You may have to remove the cover and watch the clutches in action while the cart is in motion to make sure that it is indeed the drive belt that is slipping.
How to remove drive belt?
Removing the drive belt involves holding the belt with both hands in the center between the driven and drive clutches and lifting the belt. You must now rotate the driven clutch counter-clockwise and slip the belt off the sheave. You can then slide the drive belt off the drive clutch.
Why is my club car drive belt so tight?
The reason for a Club Car drive belt being too tight can be because the drive belt is too small for the golf cart. The way to check if the belt is fitted correctly is to push the belt down with one finger at the center between the clutches. It should not deflect more than 1.5inches. It should not be less as well.
Why does my golf cart drive belt slip?
The reason for the drive belt slipping could be that it is of a larger/longer size and therefore loose. You may start feeling the slippage after driving for a while. This is because the belt gets heated up after the golf cart runs for some time and loosens further .
What happens if a golf cart belt is too tight?
If the belt is too tight then your starter will be under strain and this should be avoided. The best test to see if a golf cart drive belt has the correct tension is to use the Finger Test.
