Pry off the door pull trim piece with a flat blade screwdriver Remove the two Phillips head screws inside the door pull Pull out the manual window crank collar Pull off the window crank Remove the six T10 Torx screws from the edge of the door panel
Is there a step-by-step Volkswagen rear door removal guide?
For your convenience, our step-by-step Volkswagen rear door removal guide is also available for you to print. This Guide is for 1999-2005 VW Jetta and 1999-2006 VW Golf models
How do I remove the door panel from the window?
You need to pull out on the bottom of the panel until the bottom is no longer connected, then push up to allow the door to pop off the upper clips and up off of the lock and out of the window slot. Be careful! Your door panel is still tethered to the door itself by wires connected to the window, the light, and the lock.
How do you remove the door hinge on a Ford Explorer?
Start by disconnecting the electrical connectors for the door. In order to do this, pull back the boot right at the B-pillar. This will give you access to two connectors you will need to disconnect Loosen the top bolt with the door shut, this will make it easier to remove Now with the door open, you gain access to the bottom bolt on the door hinge
How do I remove the front passenger side door handle?
The part you grab on the passenger side door has a ridge running down the middle. Use a flat head screwdriver, or pocket knife, protected by a cloth so as not to damage the handle, to wedge a gap in between the two pieces of the handle. The side facing into the car will now pop off (picture 1), and reveal a couple Philips head screws.
Step 1: Remove the Inside Door Handle
This car is built with plastic snaps that keep together a majority of the plastic panels, handles, and latches. The part you grab on the passenger side door has a ridge running down the middle. Use a flat head screwdriver, or pocket knife, protected by a cloth so as not to damage the handle, to wedge a gap in between the two pieces of the handle.
Step 2: Remove Door Panel Screws
You will need a T20 Torx bit to remove 3 screws at the bottom of the door panel, hidden under the edge as pictured. There is also one other sneaky screw on the inside edge of the door, near the top. You will need to open the door as far as possible, and still may have trouble getting an angle at the screw.
Step 3: Mind the Tricky Parts
Once the door panel is completely off and disconnected, do whatever you took the door panel off to do. (DUH)
Step 4: Reassembly
To put your door back together, first reconnect all of the electrical components. Then make sure the door latch hook is put back in the hole in the inside of the inner door latch. Raise the door panel over the locking mechanism such that it lines up with the hole. This is easiest to do while holding the lock steady from under the panel.
