How to Remove a Golf Shaft From the Head
- Remove the ferrule. The ferrule is the small plastic band that sits just above the hosel. ...
- Place the club in a vise to position it for shaft removal. The club should lie horizontally. ...
- Heat the glue inside the hosel. The hosel is the area where the shaft fits into the clubhead. ...
- Clean excess glue out of the hosel to make a comfortable fit for the new shaft. ...
How do you get rust off a golf club head?
Step 1: Things You'll Need
- Fine Steel Wool
- Hard bristle toothbrush
- Wet and Dry sandpaper (as fine as you can get it)
- White Vinegar
- Metal Polish
- A bucket
- A Dremel or similar rotary tool with a polishing bit (not necessary, rags will do)
- Plenty of elbow grease!
How to clean a golf club the right way?
How to Clean Golf Clubs
- Gather Cleaning Materials. What do you need to clean golf clubs at home? ...
- Get Sudsy. Squirt a little of the dishwashing liquid into the bottom of your plastic bucket, then add warm water to create suds.
- Place Your Irons In the Bucket. ...
- Clean Out the Grooves. ...
- Rinse Off the Clubhead. ...
- Dry the Clubhead and Shaft. ...
- Cleaning Woods. ...
How do you clean rust off of golf clubs?
Steps on how to clean rust off golf clubs
- Pour the vinegar into the bucket. The vinegar should be enough to cover the entire clubhead when dipped into the bucket. ...
- Start scrubbing. While the clubhead is dipped into the vinegar, cup your hand to splash some vinegar to the shaft. ...
- Sand the deeply rusted parts. ...
- Brush the grooves. ...
- Clean the handle. ...
- Wipe and dry. ...
- Buff it. ...
How to regrip a golf club?
- How to Regrip Golf Clubs 1. Take Off the Old Grip 2. Add Grip Tape 3. Apply Solvent Solution 4. ...
- How to Choose the Right Golf Grips to Regrip Your Golf Clubs Size Firmness Weather Conditions Texture
- Types of Golf Grips Wrapped Corded Rubber Hybrid
- Cleaning Golf Grips
- When to Regrip Golf Clubs
- Signs Your Club Grips Need to Be Replaced
- Final Thoughts
How do you remove a wedge head from a shaft?
0:042:32How To Remove A Steel Golf Shaft From A Golf Club - YouTubeYouTubeStart of suggested clipEnd of suggested clipYou can also use a heat gun but it's going to take three times as long. The other things that you'reMoreYou can also use a heat gun but it's going to take three times as long. The other things that you're going to need or a club making vice vice clamp some heavy-duty gloves and probably a knife.
How are golf club heads attached to the shaft?
Golf Club Epoxy. Adhesives are used in many different sports equipment bonding applications. One such application is that of bonding heads onto shafts for golf clubs. It sounds like an easy application and in principle it is – put some adhesive on the tip of the shaft and then insert it into the club head.
How do you remove iron club heads from graphite shafts?
As you apply heat to the hosel (by keeping the heat moving around the whole area), you should periodically try and twist the head and shaft. If they don't budge, keep applying heat. Eventually you will feel the epoxy break and will be able to twist the head off.
How do you replace a golf driver head?
0:045:16Golf Club Repair - Removing the driver head and cleaning & preppingYouTubeStart of suggested clipEnd of suggested clipWe can take the old shaft out of the shaft extractor here pretty easy to get the old shaft out justMoreWe can take the old shaft out of the shaft extractor here pretty easy to get the old shaft out just loosen up the screws. Take the protective film off the shaft. So you don't scratch it.
How do you replace a iron head on a golf club?
2:3522:36GOLF CLUB BUILD - How to reshaft your irons Step by Step - YouTubeYouTubeStart of suggested clipEnd of suggested clipPull the shafts you don't need a shaft puller. Anything like that you can just heat them up andMorePull the shafts you don't need a shaft puller. Anything like that you can just heat them up and twist them off because it's a steel shaft.
What glue is used for golf club heads?
Golf club heads are attached to the golf shaft with epoxy glue. Epoxy is a thermosetting polymer that is a high strength adhesive. Two parts, the resin and the hardener, are mixed together to create a chemical reaction that cures the epoxy to hardness.
How do you remove graphite shaft without a puller?
0:353:50How To - Pull a graphite golf shaft - YouTubeYouTubeStart of suggested clipEnd of suggested clipAgain using a butane torch you can actually really focus the heat which is a lot better than sayMoreAgain using a butane torch you can actually really focus the heat which is a lot better than say trying to use a heat gun which could end up damaging. The fibers of the golf shaft.
How do you make a golf club shaft extractor?
0:296:43Build your own golf club shaft extractor - YouTubeYouTubeStart of suggested clipEnd of suggested clipAnd put four bolts in it to hold it to a piece of heavy angle iron just actually is quarter-inch 2x4MoreAnd put four bolts in it to hold it to a piece of heavy angle iron just actually is quarter-inch 2x4 bent angle out of stainless steel.
Can you pull a graphite shaft without a shaft puller?
Well, the general process for pulling a graphite shaft is just about the same, but there are a few key differences. You need to take more care and HAVE to use a shaft puller. Otherwise, your new fancy and expensive exotic shaft could be at serious risk for major damage.
Can you put any driver head on any shaft?
Yes, most golf Driver shafts are interchangeable. Golf driver shafts can be replaced as long as the new shaft is the same length and made by the same brand of golf club.
How do you Reshaft a driver at home?
0:144:53How To Reshaft Golf Clubs - YouTubeYouTubeStart of suggested clipEnd of suggested clipHere just as the pocketable bandha looks better with it as you can see two of ours also prep the tipMoreHere just as the pocketable bandha looks better with it as you can see two of ours also prep the tip taken basically the paint off the shaft that way to here to the epoxy.
How to prepare a club head for a new shaft?
Prepare the hosel of the club head for your new shaft by removing the old epoxy from inside it. The easiest way is to first put the club head into a vise , making sure you don't damage it. Then use a hand drill to carefully remove the debris.
How to loosen epoxy on golf club shaft?
Move the plastic ferrule from its position next to the club head to a position up the shaft so that it will be out of the way and won't be damaged when you apply heat. Step 3. Use a blowtorch or a heat gun to loosen the epoxy that fused the shaft to the club head. ...
How to remove epoxy from golf club?
Use a blowtorch or a heat gun to loosen the epoxy that fused the shaft to the club head. Depending on the age of your club, it could take a minute or two before the epoxy begins to liquefy. Once it melts, carefully remove the shaft from the club head, take off the ferrule from the shaft and set it aside. Since the club head can get quite hot, wear ...
What to do if your golf club shaft is bent?
If the shaft of your golf club is bent or broken, do not discard the entire club. Instead, remove the clubhead from the damaged shaft and install it on a new one. Disconnecting the golf club shaft from the head also allows you to try the latest shaft technology on the market without purchasing a whole new club.
How to remove ferrule from golf club?
Step 1. Use a utility knife to scrape off the ferrule at the connection point between the shaft and the clubhead. Scrape down toward the head and away from your body.
Introduction
Steps to replace an old golf club shaft with a new steel shaft and replace an old grip with a new one.
Step 1 Golf Club Steel Shaft and Grip
Using propane or a torch, heat the hosel of the club to remove the steel shaft from the club head. The heat will break the epoxy bond that holds the head to the shaft.
Step 2
Use a wire brush to clean out the remains of the old epoxy from the club head.
Step 3
Use a piece of sand paper or a grinder to roughen the tip of the shaft where it connects to the hosel of the club head.
Step 4
Pour epoxy into a container and stir to mix it together. Once epoxy is mixed together, spin the shaft tip into the epoxy to prepare for insertion into the head.
Step 5
Insert the shaft into the club head. Hold the head and shaft together for approximately 30 seconds to secure.
Step 6
To replace the grip of the club, place the club on a level surface where you can cut a straight line through the grip using a razor blade or a utility knife.
How to remove graphite shaft?
One method to remove a graphite shaft is to remove the ferrule, cut the shaft off at the hosel and drill the remaining part out of the hosel. However, on modern drivers, fairways and hybrids which are nearly all hollow inside, could potentially could push material into the cavity of the head and cause it to rattle.
How many times can you remove graphite from a clubhead?
Sometimes these steps will have to be repeated as many as 3 or 4 times (or more) before successfully removing the graphite shaft from the clubhead, especially for titanium and aluminum clubheads. The more pressure that the shaft puller applies the less heat it takes to remove the shaft from the clubhead.
What is a graphite shaft made of?
A graphite shaft is made from many layers of graphite pre-preg or long continuous strands of carbon fiber wrapped around a forming mandrel. To hold the layers or strands together, an epoxy resin is used. This same epoxy resin is not much different from the epoxy that is used to hold the head onto the shaft. In order to remove the head ...
How long to reheat a golf club?
If the clubhead does not come off at this point, reheat for a period of 25-30 seconds. Remember, you can always reheat the hosel, but you can’t remove heat if you heat the club too long. Continue this method of heating for 25 second intervals until the shaft puller has forced the clubhead from the shaft.
How much does a shaft puller cost?
Shaft pullers can range anywhere from around $20 for a devise that looks like a modified pry bar (you still need a vise and shaft clamp) to several hundred dollars for a hydraulic model. Regardless, invest in a good shaft puller if you are repairing clubs in any sort of volume. Remember how much shafts cost again.
Can you discolor a golf club head?
If you do discolor the head, at least it will be on the back side that it least likely to be seen by the golfer when the club is at address. You are now ready to apply heat to the head for the purpose of removing the head from the shaft. It is best to remove the shaft as soon as the epoxy breaks loose.
Series Navigation
In this video, I show you how to remove the putter head from the shaft. I use a propane torch, but a heat gun would suffice too. This technique can be used for irons, wedges, etc.
Series Navigation
Hey!! I'm Zach, the founder of The DIY Golfer. I created this site in 2015 while playing D1 collegiate golf to help myself understand the game of golf better and improve as a player. Fast forward a few years, and it has become much more than a journal.
Series Navigation
It is important to know the proper technique for removing a graphite shaft. A graphite shaft could be ruined forever if removed by the conventional twist and pull method that we use for steel shafts. The fibers in the shaft tear apart when you do this. In this video, I will show you the correct (and cheap) way to remove a graphite shaft.
Removing an Adapter from a Wood or Driver
The process for removing an adapter is very similar to removing a graphite shaft with a minor twist as shown in the video below.
