How Do I Remove the Shaft of a Golf Club?
- Place the shaft, or what remains of it if it is broken, in a vise parallel to the floor. Secure the shaft in the vise.
- Apply heat evenly to the hosel for about a minute, using a heat gun or heat torch. ...
- Remove heat from the hosel and twist the club head counterclockwise. It should twist off fairly easily.
- Clean out any remaining epoxy in the hosel. ...
How do I clean up golf club shafts?
Prevention is Better Than Cure
- Wipe your clubs down with cotton after every round
- Wipe your clubs with a multipurpose lubricant in every few months
- Never store them in a humid location i.e. garage, corner of a storeroom.
- Closely monitor the clubs once a month.
- Spray rust remover on metal club heads and shafts. ...
- Dry out properly before storing your clubs if they get wet.
How do you replace a golf club shaft?
How To Re-Shaft Your Steel Golf Clubs
- Carefully clamp the shaft into a vise using a Shaft Vise Clamp. ...
- When removing steel shafts from clubheads, use a torch to heat the hosel. ...
- After 30 seconds of heating, with your gloved hands grasp the head and twist/pull the head. ...
- Using a wire brush remove excess epoxy from the inside of the hosel.
How much does it cost to reshaft a golf club?
So, how much does it cost to reshaft a golf club? To reshaft a golf club, you’re likely to spend between $20 to $200 per club. The cost of reshafting your golf clubs will vary greatly depending on where you go to have it done. The cost will depend on the cost of the labor, the number of clubs, and the cost of the new shafts.
How to reshaft a golf club?
Update Your Golf Club With a New Shaft
- Steel Shafts: To remove a steel shaft from a metal wood or iron, place the shaft in a super lock tight shaft holder. Tighten the STSL in a vise. ...
- Measure the shaft tip. ...
- After the tip has been trimmed, abrade or roughen the shaft tip. ...
- Align the shaft graphics the way you want them by rotating the shaft. ...
- Position the club in the normal playing position. ...
How do you remove a golf shaft at home?
0:272:32How To Remove A Steel Golf Shaft From A Golf Club - YouTubeYouTubeStart of suggested clipEnd of suggested clipYou can also use a heat gun but it's going to take three times as long. The other things that you'reMoreYou can also use a heat gun but it's going to take three times as long. The other things that you're going to need or a club making vice vice clamp some heavy-duty gloves and probably a knife.
How do you remove and replace a golf club shaft?
0:335:54Golf Equipment : How to Change a Golf Shaft - YouTubeYouTubeStart of suggested clipEnd of suggested clipTool so we lay it in in this little groove right here. Which is going to slide back and forth andMoreTool so we lay it in in this little groove right here. Which is going to slide back and forth and put pressure and pull on the head. As the shaft is heated. Then we tighten the shaft.
How do you change a shaft on a golf club?
0:5210:45How to replace a golf club shaft - Step by Step - YouTubeYouTubeStart of suggested clipEnd of suggested clipBefore you actually put the new shaft in you'll need a ferrule. It's a kind of a presentation on topMoreBefore you actually put the new shaft in you'll need a ferrule. It's a kind of a presentation on top of actual iron cell to make it look nice.
How do I remove a shaft adapter without a puller?
1:594:14Simple Taylor Made shaft adapter removal 30 sec without shaft pullerYouTubeStart of suggested clipEnd of suggested clipAll right take the head on see that moves really easy and so you just keep kind of twisting. AndMoreAll right take the head on see that moves really easy and so you just keep kind of twisting. And pulling keep the head locked in and eventually it will come all the way. Off.
Is it easy to change golf shafts?
Shafts can be replaced at golf pro shops and most golf stores, but it is also a fairly easy project to do yourself. Replacing your own shaft can save time and money, and allow you to try a new shaft without purchasing new clubs.
How do you remove driver shaft?
0:344:28How To Remove A Graphite Shaft From A Golf Club - YouTubeYouTubeStart of suggested clipEnd of suggested clipSo you needed a special tool called a graphite shaft puller you're several on the market. That areMoreSo you needed a special tool called a graphite shaft puller you're several on the market. That are commercially available but they do essentially the same thing they securely clamp the shaft.
Is it easy to Reshaft irons?
Golf irons can be a bit easier to reshaft than a driver. If you are reshafting with steel irons, it is usually pretty straightforward. However, you will need the proper tools and space to complete this project.
Can you change the shaft on irons?
If you're thinking about changing the shafts on your golf clubs, you can either do them yourself or take them to your local golf shop.
How do I remove a golf shaft adapter?
0:139:32How to Remove Golf Shaft Adapter - YouTubeYouTubeStart of suggested clipEnd of suggested clipOnce you start to see it's a bubble up a little bit just take your hook blade. Slide it right underMoreOnce you start to see it's a bubble up a little bit just take your hook blade. Slide it right under there. And it should come off free easy a little cold out here in the shop tonight.
How much does it cost to replace a golf club shaft?
The average cost to reshaft your golf clubs is $24 per club plus the cost of the shaft and grip. A new iron shaft and grip can range between $10 and $95 while a new driver shaft and grip can range between $18 and $440. The majority of the cost comes down to what type of shaft you want and what grips you like.
Can you change the shaft on irons?
Reshafting is just one way to keep your clubs performing at a high level. You can also benefit from regripping your clubs. Replacing worn-out golf grips can help make your clubs feel new again. Adding the right shaft to your favorite clubs can get you back on the course and working toward a new personal low round.
How do you Reshaft a driver at home?
0:144:53How To Reshaft Golf Clubs - YouTubeYouTubeStart of suggested clipEnd of suggested clipHere just as the pocketable bandha looks better with it as you can see two of ours also prep the tipMoreHere just as the pocketable bandha looks better with it as you can see two of ours also prep the tip taken basically the paint off the shaft that way to here to the epoxy.
How do you install a golf shaft?
4:297:38How to Install Graphite Golf Shafts - YouTubeYouTubeStart of suggested clipEnd of suggested clipRemove the head and place some epoxy inside the hosel dip the tip of the shaft into the epoxy mix.MoreRemove the head and place some epoxy inside the hosel dip the tip of the shaft into the epoxy mix. And then install into the head rotate.
How to make a golf club with masking tape?
Step 1. Completely cover the head of the club with masking tape to prevent the head from being scratched during the process. Now, place the club in the vise, so that the middle of the shaft is the part being held in the vise. Make sure the club is held securely.
Can you replace a golf club shaft instead of replacing the entire club?
By Tami Fisher. Replacing a golf shaft instead of replacing the entire club can save money. Once in a while, something happens to cause a golf club shaft to splinter or even break. When this happens, the old shaft must be removed and a new one installed in its place.
How to melt glue on a golf club?
Heat the glue inside the hosel. The hosel is the area where the shaft fits into the clubhead. Light your propane torch and apply heat to the underside of the hosel. This will melt the glue.
How to remove a ferrule from a hosel?
The ferrule is the small plastic band that sits just above the hosel. With a utility knife or box cutter, cut a vertical slit in the ferrule. Using a flathead screwdriver or pliers, pry the ferrule from the shaft and discard it.
Do you need to reshaft a golf club?
The need to reshaft golf clubs is common. It is sometimes necessary to have a professional tackle a complete reshaft job; however, it can make his job easier if you eliminate a step in the process. Removing a golf shaft from the head is fairly simple; however, it must be done carefully and properly.
Step 1
Put on protective gloves and keep them on until the procedure is complete.
Step 2
Heat the hosel (small metal joint linking the shaft to the club head) with a heating gun. Be sure to dispense heat evenly on all sides of the hosel and don't be alarmed if small amounts of white smoke begin to escape the hosel cavity. That is just the old epoxy melting.
Step 3
Place the grip end of the club on the ground so the head end is sticking straight up and gently pull the head off the shaft. Do not twist, especially if you want to reuse the shaft or sell it, as twisting may harm the inner walls of the hosel as well as the tip of the shaft.
Step 4
Allow the club head to cool completely once its been liberated from the shaft.
Step 5
Roll up a small piece of sandpaper and use it to clean out any remaining epoxy residue inside the hosel joint, making it ready for the insertion of a new shaft.
How to remove graphite shaft?
One method to remove a graphite shaft is to remove the ferrule, cut the shaft off at the hosel and drill the remaining part out of the hosel. However, on modern drivers, fairways and hybrids which are nearly all hollow inside, could potentially could push material into the cavity of the head and cause it to rattle.
How many times can you remove graphite from a clubhead?
Sometimes these steps will have to be repeated as many as 3 or 4 times (or more) before successfully removing the graphite shaft from the clubhead, especially for titanium and aluminum clubheads. The more pressure that the shaft puller applies the less heat it takes to remove the shaft from the clubhead.
What is a graphite shaft made of?
A graphite shaft is made from many layers of graphite pre-preg or long continuous strands of carbon fiber wrapped around a forming mandrel. To hold the layers or strands together, an epoxy resin is used. This same epoxy resin is not much different from the epoxy that is used to hold the head onto the shaft. In order to remove the head ...
How long to reheat a golf club?
If the clubhead does not come off at this point, reheat for a period of 25-30 seconds. Remember, you can always reheat the hosel, but you can’t remove heat if you heat the club too long. Continue this method of heating for 25 second intervals until the shaft puller has forced the clubhead from the shaft.
How much does a shaft puller cost?
Shaft pullers can range anywhere from around $20 for a devise that looks like a modified pry bar (you still need a vise and shaft clamp) to several hundred dollars for a hydraulic model. Regardless, invest in a good shaft puller if you are repairing clubs in any sort of volume. Remember how much shafts cost again.
Can you discolor a golf club head?
If you do discolor the head, at least it will be on the back side that it least likely to be seen by the golfer when the club is at address. You are now ready to apply heat to the head for the purpose of removing the head from the shaft. It is best to remove the shaft as soon as the epoxy breaks loose.
Series Navigation
It is important to know the proper technique for removing a graphite shaft. A graphite shaft could be ruined forever if removed by the conventional twist and pull method that we use for steel shafts. The fibers in the shaft tear apart when you do this. In this video, I will show you the correct (and cheap) way to remove a graphite shaft.
Removing an Adapter from a Wood or Driver
The process for removing an adapter is very similar to removing a graphite shaft with a minor twist as shown in the video below.
