how to replace a 36 volt golf cart solenoid for club cart ds

What is the voltage on a golf cart solenoid?

NOTE: When buying a new solenoid, be sure to buy one that matches your cart's voltage. Most golf carts are either 36 volts or 48 volts. The voltage will usually be written on the side of the solenoid.

How to fix a golf cart solenoid that won’t start?

Connect the two high side large wires to the large terminals of the solenoid. Try to start the golf cart after establishing this connection. If the cart does not start, then it is a clear sign that your solenoid does not have a problem. However, if it does, this does not indicate that the solenoid is the cause of the problem.

How to troubleshoot your club car golf cart?

Club Car Golf carts have evolved many times since 1975, and although the basic electrical design has stayed close to the same, there are small differences. These differences are important when troubleshooting your cart. 1. Battery connections 2. Discharged batteries 2. Failed switch 1. Loose Wires 2. Failed Switch 3. Cam not Activating Micro Switch

How do you change a solenoid on a Club Car golf cart?

1:305:38Replace Solenoid in Golf Cart - YouTubeYouTubeStart of suggested clipEnd of suggested clipSo you start by removing the bolts that actually hold the solenoid to your golf cart wherever thatMoreSo you start by removing the bolts that actually hold the solenoid to your golf cart wherever that might be. And one of the tips i also like to mention is hold up your new solenoid.

How do I test my Club Car DS solenoid?

Set your multimeter to ohms and insert a probe on each large terminal with the key off and the cart direction switch in the neutral position. Press on the accelerator with the cart's movement control in the forward position, and the key is turned on. A click should be heard first from the solenoid.

How do you hook up a 36 volt golf cart solenoid?

3:418:12How to Replace Golf Cart Solenoid Coil | Install - YouTubeYouTubeStart of suggested clipEnd of suggested clipGoing back across the two small terminals. So what you'll do is we'll hook on one side bring itMoreGoing back across the two small terminals. So what you'll do is we'll hook on one side bring it around and using your needlenose. Just hook it around the terminal.

How do you test a 36v solenoid?

0:182:58Solenoid Troubleshooting - YouTubeYouTubeStart of suggested clipEnd of suggested clipTroubleshooting this solenoid is actually quite simple in order to troubleshoot the solenoid we'llMoreTroubleshooting this solenoid is actually quite simple in order to troubleshoot the solenoid we'll use the continuity feature of our multimeter we can either use continuity or the resistance feature.

Can you bypass solenoid on golf cart?

To bypass the solenoid of your golf cart, simply connect both the large side wires of terminals of the solenoid. And after making the connection, attempt to start the cart. If you fail to start, this is an indication that there is no problem with your solenoid.

Can you bypass a solenoid?

5:037:29Solenoid Bypass - YouTubeYouTubeStart of suggested clipEnd of suggested clipAll you have to do to bypass the solenoid. And make the starter turn is basically connect this hardMoreAll you have to do to bypass the solenoid. And make the starter turn is basically connect this hard copper wire to this point on the battery. Then you're not doing anything with the solenoid.

How many wires are connected to a solenoid?

A solenoid consists of a single electrical component, namely its coil. The coil requires only the connection of two wires running to the live and neutral points of the power supply in the case of an alternating current (AC) solenoid or the positive and negative points of a direct current (DC) example.

Is there a positive and negative on a golf cart solenoid?

In a 2002 EZGO TXT PDS golf cart, the yellow wire is connected to the positive side small terminal of the solenoid. The blue wire is connected to the negative side small terminal of the solenoid. The red wire connection is done to the large terminal post that is closer to the battery.

Why does my golf cart click but not move?

A Club Car golf cart can start clicking but not move, due to dust accumulating inside the battery ports. Opening the battery ports and checking whether there is any dust accumulation can tell you if this is the case. Cleaning it thoroughly with a cloth can resolve the problem.

How do I test my Club Car DS controller?

To test a club car precedent controller, connect a voltmeter between the negative terminal of your cart's battery and the M terminal on the controller. Then push the pedal down and look for a clicking noise from the solenoid. Your batteries should read as full.

Where is Club Car solenoid?

0:494:43Club Car Precedent 48 Volt Solenoid | How to Replace on Golf CartYouTubeStart of suggested clipEnd of suggested clipAs we can see we have our cylinder it right here right there in front of us we want to disconnect.MoreAs we can see we have our cylinder it right here right there in front of us we want to disconnect. It. Pull the spades off. Move this wire out of the way.

Why is my solenoid not clicking?

If you do hear clicking, the solenoid may be engaging, but not sufficiently. Hearing clicking without the starter motor moving means the solenoid is transferring the electricity, but it may not be enough. No clicking means the solenoid is not properly engaging, but this may also be due to a dead battery.

How do I test my Club Car DS controller?

To test a club car precedent controller, connect a voltmeter between the negative terminal of your cart's battery and the M terminal on the controller. Then push the pedal down and look for a clicking noise from the solenoid. Your batteries should read as full.

Why does golf cart solenoid fail?

It's likely that the solenoid can no longer send electricity out to power the golf cart. In some cases, this happens because the coil of the battery is worn out or is too old. It can also be a sign of a faulty battery or even loose connections within the solenoid.

What does a starter solenoid do on a golf cart?

For a gas golf cart, the function of the solenoid in a golf cart motor is to use a small amount of electricity (made possible by turning on the ignition switch) to close two heavy-duty contacts that are needed to get the starter turning over. It also functions in the same way with an electric golf cart.

Why does my electric golf cart have no power?

If you're lucky, the problem could be as simple as a loose wire or a broken coil. In some cases, corrosion can also be a factor. If you suspect a faulty solenoid, your best bet is to take your cart to a repair shop. A mechanic can diagnose the problem and replace the solenoid if necessary.

What is a solenoid on a golf cart?

A solenoid, for our purposes, is a type of relay. A relay is a type of switch that uses a low power circuit to operate a high power circuit. A solenoid uses a magnetic coil (the actual solenoid) on a low power circuit to push a rod that closes a high power circuit. On your golf cart, this high powered circuit is either your ignition on ...

Why does my golf cart have no solenoid?

Golf cart solenoids are also typically one of the first components to fail in your golf cart, because they work very hard, turning on and off every time you stop and go in your golf cart. If you have an issue with no start or no go then your solenoid should be pretty high on your list of things to check.

What is a golf cart go switch?

On your golf cart, this high powered circuit is either your ignition on a gas golf cart or your electrical motor power circuit for an electric golf cart. Basically it’s your golf cart’s go switch, and it’s absolutely essential to your golf cart’s ability to do its job. Golf cart solenoids are also typically one of the first components ...

What happens if a solenoid reads infinity?

If it reads infinity or open lead, then the solenoid has an internal fault and requires replacement. Your solenoid should also have a range that it operates in, and if the resistance reads outside of that range, you should replace the solenoid even if it works to avoid damaging other components.

What is the most important part of a golf cart?

One of the most important components of your golf cart is the solenoid. It is one of the main components of your golf cart that allows it to move. Whether you have a Yamaha, E-Z-GO, or Club Car golf cart, and no matter if it is an electric or gas golf cart, you need a properly operating solenoid to get anywhere. Contents [ show]

What to do if your solenoid doesn't work?

Before you run out and get a solenoid, you’ll have to test the entire ignition system this way to find out what’s not working, and it is a bit of a pain.

What is a micro switch on a gas pedal?

This switch is what sends the low power to the solenoid. The solenoid uses this to create a circuit between the battery and the starter, thus starting your motor and getting you grooving.

Where are the solenoids on a golf cart?

In all golf carts, new and old, the solenoids can be found under the seat or in the engine well and are easily identifiable by the wires that lead to them. Banks of heavy duty solenoids, as in the previous illustration, are mounted on the side or back panel near the electric motor.

How to test golf cart solenoid?

A diode allows current to run in one direction, but not in the other. Testing the diode is a simple procedure. Remove the diode from the circuit and check the leads with a continuity tester.

Why doesn't my golf cart solenoid click?

This can be a faulty wire connection, but can also mean the solenoid is beginning to fail. The golf cart solenoid doesn’t click when the accelerator is pressed. This again can be faulty wiring or a failed solenoid.

What to do if your solenoid is not zero?

If the reading is not zero, then the solenoid is stuck and needs to be replaced. If the ohmmeter does read zero, set the cart to forward travel and turn the key switch on. Press the accelerator pedal (or have a friend do it) and you should hear a click. If you don’t hear a click, measure the resistance anyway.

How to tell if solenoid is bad on golf cart?

The common symptom of a bad solenoid is no clicks when the cart’s ignition is on and you press the accelerator.

How to tell if a golf cart won't start?

The first and most obvious symptom is the golf cart won’t start. If it is a gas-powered cart, the engine doesn’t turn over, and if it is an electric cart, the cart doesn’t move. Now, on to the next symptoms…. The engine on the gas-powered cart starts, but the starter doesn’t disengage after starting.

Is a solenoid an electromagnet?

A solenoid is NOT an electromagnet, but like an electromagnet, it IS a coil of wire, partially surrounding an iron core, that is made to move inside the coil by the magnetic field caused by current flowing through the coil. It is used to convert electrical energy to mechanical energy, as in the operation of a switch.

What voltage is applied to the two small terminals to activate the solenoid?

Battery voltage is applied to the two small terminals to activate the solenoid, which then connects the two large terminals together. From time to time, the two large terminals malfunction and the solenoid needs to be replaced.

How to check a solenoid?

Follow These Simple Steps to Check the Solenoid: 1. You will need a couple of tools: a voltmeter or multimeter, and (typically) a ½” wrench. 2. Disconnect any cables from the two large terminals. Be sure to wrap the cable ends in tape, and keep the ends separate from each other. 3.

What is a golf cart?

Golf carts are also known as golf cars. The term "cart", in its purest sense, refers to a vehicle that does not travel under its own power. Golf cars, however, are most commonly referred to as golf...

When did golf carts evolve?

Club Car Golf carts have evolved many times since 1975, and although the basic electrical design has stayed close to the same, there are small differences. These differences are important when troubleshooting your cart.

What is a solenoid in a golf cart?

A golf cart solenoid is one of the major components of any golf cart. This part is essential regardless whether you own an electric or gas golf cart because both types primarily rely on a solenoid for their movement. What this means is whichever brand or model you choose for your cart, a solenoid is truly an indispensable part of the vehicle.

How to get a golf cart going without a glitch?

To get your golf cart going without a glitch, you most definitely need the solenoid of your cart to be functioning properly. Thus, it goes without saying that you must check this component occasionally to monitor its performance so that you don’t get stranded mid-way.

What is a solenoid wiring diagram?

A solenoid wiring diagram can be very helpful in guiding you about the various connections made to and from the solenoid. This can come in handy when you set out to troubleshoot a problem in your cart on your own. The solenoid wiring diagram is generally very simple, straightforward and self-explanatory.

What does the inductive throttle sensor do on a golf cart?

When you push down the pedal of the golf cart downwards, the inductive throttle sensor sends out the first low power signal to activate the solenoid on its low side and the speed controller. The low side is the steel rod of the solenoid.

How often do solenoids work?

Since solenoids need to work very frequently; turning on and off each time you use the cart, they are prone to wear and tear easily. This is not surprising as they can switch on and off as much as 1,500 times a day). One of the first indications that a solenoid is faulty is when your cart fails to start.

Why is my golf cart not clicking?

This may be because the safety reed switch is not working properly in the charger socket. There could be a loose connection of the MOLEX plug.

Why does my gas cart not turn over?

In a gas cart, a bad solenoid prevents the starter from being engaged and therefore results in the engine not turning over.
