Lift the rear of the golf car and place the jack stands in a secure spot that will support the golf car. The following steps will allow for optimal adjustment: Remove both wheel assemblies. Release the brake pedal parking brake. Back off the brake cable adjusting rod, so there is not any cable tension on the shoe lever arm.
Full Answer
How do you replace the rear brakes on a golf car?
Lift the rear of the golf car and place the jack stands in a secure spot that will support the golf car. Remove both wheel assemblies. Release the brake pedal parking brake. Back off the brake cable adjusting rod, so there is not any cable tension on the shoe lever arm. Remove the brake drum.
How do you adjust the rear brake shoes?
Note: For manually adjusted shoes put the drum back on the axle, turn the adjuster screw or star until the drum locks up. At this point, back the adjuster off 3-5 clicks and at this point the drum should turn freely. Put the ties back on and torque the lugs to 50lbs. Adjust the brake pedal height. (Do not confuse this with brake shoes adjusting.)
How do I lift and support the golf car?
Note: Use proper lifting equipment and proper jack stands to support the golf car. Note: Some electric cars will have a run/tow switch. The run/tow switch must be moved to the tow position before disconnecting the battery packs. Lift the rear of the golf car and place the jack stands in a secure spot that will support the golf car.
How do I tow an electric golf car?
Note: Some electric cars will have a run/tow switch. The run/tow switch must be moved to the tow position before disconnecting the battery packs. Lift the rear of the golf car and place the jack stands in a secure spot that will support the golf car.
How do you adjust brake shoes on a Club Car golf cart?
2:474:18How to adjust golf cart brake pedal/brakes - YouTubeYouTubeStart of suggested clipEnd of suggested clipIf you're really concerned about it doesn't tend to turn on its own but you can get two wrenches inMoreIf you're really concerned about it doesn't tend to turn on its own but you can get two wrenches in here and tighten them together make it extra secure. And when you're done. Put your wrench.
How do you change the brakes on a Club Car DS?
0:5824:4988-94 Club Car DS Brake shoe replacement - YouTubeYouTubeStart of suggested clipEnd of suggested clipSlide your finger along the inside and you should not feel the lip you shouldn't feel any roughness.MoreSlide your finger along the inside and you should not feel the lip you shouldn't feel any roughness. I'm doing this with my phone so sorry about the crazy angles.
How do you remove the brake drum on a golf cart?
How to remove brake drums on a golf cart?Remove the rubber Grommet from the rear end of the braking assembly.Using a screwdriver, push into the hole of the automatic adjuster to unlock it.Next insert a second screwdriver to rotate the lock wheel.Then safely open the drum.
How do you check brakes on a Club Car golf cart?
Jack up the cart. Drive your cart onto a level surface, and then jack up the rear wheels using the floor jack. Brakes on a Club Car are only on the back two wheels, so you will not have to repeat the process on the front wheels. Remove the wheels with the socket wrench, most Club Cars use a 3/4-inch socket.
How do I know if my golf cart brakes are bad?
Much like a regular car, one of the ways you know that your brakes are starting to go bad is when they start making a squealing sound. The squealing will signify that the brake pads are actually wearing down. Another sign that your brakes have started to go bad is when the feel of your brake pedal changes when pressed.
How do you tell the year of a Club Car golf cart?
The serial number of each vehicle is printed on a bar code decal. The two letters at the beginning of the serial number "A" indicate the vehicle model. The following four digits "B" indicate the model year and production week during which the vehicle was built.
How do you remove rear brake drums?
1:516:48How to Remove a STUCK Drum Brake - YouTubeYouTubeStart of suggested clipEnd of suggested clipAnd don't be afraid to hit this hard so now as you're trying to take this off you're trying to doMoreAnd don't be afraid to hit this hard so now as you're trying to take this off you're trying to do like a wiggle back and forth motion as you're pulling. So I'm pulling and wiggling it back and forth.
How do you take apart drum brakes?
Unscrew the brake drum if needed. Use a screwdriver to remove the screws securing the brake drum to the wheel. Draw the brake drum forcefully towards you. Use a screwdriver and rubber mallet or a brake drum puller to take the drum off of the wheel if you are unable to remove the drum by unscrewing it and pulling it.
How do you put a brake drum back on?
3:474:42How to Replace Drum Brakes on Your Car - YouTubeYouTubeStart of suggested clipEnd of suggested clipBecause the new brake pads are thicker. Then slide the drum back on. And see how it feels.MoreBecause the new brake pads are thicker. Then slide the drum back on. And see how it feels.
How much does it cost to replace brakes on a golf cart?
The brake system in a golf cart is made of several components. Replacing the brake system will mean replacing all the components. A complete brake replacement costs $150-$200.
Are golf cart brakes self adjusting?
Many modern golf carts have self-adjustment brakes and do not require manual adjustment, but they do need a little bit of tweaking here and there. However, if you feel the brakes need adjustment, you can do so manually as well.
What causes golf cart brakes to lock up?
Why Do Golf Cart Brakes Lock Up? Golf cart brakes can start locking up when the brake cable gets stuck, or when the bolts on the lift kit are loose. The brake cable gets stuck because of a binding, resulting in a mechanical linkage. One or more parts of the pivot assembly have rusted.
How to adjust self adjusting brakes?
Note: For self-adjusting brakes, the drums should slide on and off and turn freely without any resistance. If it is too tight, take the drum back off and back off the star adjuster until the drum is free to turn 360 degrees without dragging to a stop. From this point on, the shoe will self adjust under normal operating conditions. Likewise, if the drum is too loose, you will need to tighten the shoes to a drag and then back off to free movement.
How many clicks does a brake pedal feel?
Adjust the brake pedal height. (Do not confuse this with brake shoes adjusting.) As you push on the pedal you should feel 2-3 clicks or ¾ – 1 inch free play. If you do not see this amount of travel, adjust the cable-adjusting rod that you released in Step No. 3.
Does the shoe lever have cable tension?
Back off the brake cable adjusting rod, so there is not any cable tension on the shoe lever arm.
Do you need to back off brake adjuster?
Note: On some units it may be necessary to back off the brake adjuster in order to remove the drum. Some units use an axle nut, that hold the drum in place. With this style, retain the cotter pin for use later.
