To test the starter generator: 1) Put the neutral lock-out cam in service. 2) Place the forward and reverse lever in neutral.
Full Answer
How do you test a golf cart starter generator?
How Do You Test a Golf Cart Starter Generator? Here’s a general set of instructions that should work for most golf cart starter generators. To test the starter generator: 1) Put the neutral lock-out cam in service. 2) Place the forward and reverse lever in neutral. 3) Chock the wheels.
Why is my starter generator not charging my golf cart?
Why Your Golf Cart Starter Generator is Not Charging If your starter generator is not charging properly, it may be that the solenoid, voltage regulator or brushes are faulty. If you’ve ensured that all of these parts are working fine, the starter generator may not be drawing enough current to regenerate the battery.
How many volts is a starter generator on a Yamaha golf cart?
The ideal voltage output from the starter generator in these carts is around 14-15 volts. The Yamaha G1/G9 has a forward solenoid and a reverse solenoid in place, which makes the wiring a lot more different from that in other golf carts. The starter generator has six terminals, DF, D+, A1, A2, F1, F2.
How do you test a Yamaha G1 starter generator?
How Do You Test a Yamaha G1 Starter Generator? There are four posts on the starter generator that should be labelled A1, A2, F1 and F2. Also, there should be a green wire and a red wire coming out of the side of the starter. 1) Disconnect all the wires before you begin your tests.
How do you test a golf cart alternator?
0:011:03How to Check the Generator on Your Golf Cart - YouTubeYouTubeStart of suggested clipEnd of suggested clipAnd you should see the voltage jump up from around 12 volts with the cart running to about 16 voltsMoreAnd you should see the voltage jump up from around 12 volts with the cart running to about 16 volts that that happens that proves the generator is fine you simply need to change.
How do you test a golf cart starter generator?
0:000:42Zip Tip Starter Generator Testing - YouTubeYouTubeStart of suggested clipEnd of suggested clipGround it hit your start side or your a side or your G side not the field side spin the engine up toMoreGround it hit your start side or your a side or your G side not the field side spin the engine up to speed. And while it's spinning down come over to your.
How does golf cart starter generator work?
The starter generator works in two ways; the starter portion cranks the engine and the generator portion recharges the battery. When the gas pedal is depressed the starter cranks the engine over. When it begins to run on its own, the generator portion of the unit begins to charge the 12-volt battery.
How many volts should a golf cart starter generator put out?
The ideal voltage output from the starter generator in these carts is around 14-15 volts. The Yamaha G1/G9 has a forward solenoid and a reverse solenoid in place, which makes the wiring a lot more different from that in other golf carts.
How do you jumpstart a starter generator?
0:443:36Starter Generator Field testing - YouTubeYouTubeStart of suggested clipEnd of suggested clipWith your cable. Just tap it onto it or if you're like mine you have a switch I would clamp it firstMoreWith your cable. Just tap it onto it or if you're like mine you have a switch I would clamp it first then use the switch. So you don't arc on your stud right here and burn up your threads.
How do you polarize a starter generator on a golf cart?
0:391:10How to Polarize at the Generator - YouTubeYouTubeStart of suggested clipEnd of suggested clipTake your live jumper lead and touch it touch touch. You're going to get a small spark. When that'sMoreTake your live jumper lead and touch it touch touch. You're going to get a small spark. When that's happened that's the end of it lay. Your field wire back on where she belongs. And the job is done.
How do you fix a starter generator?
0:329:20How to Your Rebuild Garden Tractor's Starter Generator - YouTubeYouTubeStart of suggested clipEnd of suggested clipTo disassemble your starter generator you simply remove these two long bolts that's holdingMoreTo disassemble your starter generator you simply remove these two long bolts that's holding everything together you'll find them on the brush. End of the starter generator.
How do I know if my generator is charging my battery?
0:031:00Generator - How to Test (version 1-28-2009) - YouTubeYouTubeStart of suggested clipEnd of suggested clipIf the generator does not make electricity. If it's not charging. The test is easy you remove theMoreIf the generator does not make electricity. If it's not charging. The test is easy you remove the field terminal. Feel wire going through the terminal right there set it down so she can't ground.
How does a starter alternator work?
The starter uses the complete opposite energy of the alternator. It uses the electrical energy of the car and turns it into mechanical energy. This energy comes from the battery and is used to start the crankshaft turn, which gets your car moving.
How do I know if my starter is bad on my golf cart?
A bad starter generator gets hot quickly when the cart starts moving around. Within a short time, it might start letting out smoke as well. Once the smoke starts coming out of it, you know that your starter generator is damaged.
How do you jump a golf cart starter?
0:065:56How to jump a dead ezgo - YouTubeYouTubeStart of suggested clipEnd of suggested clipNext we're going to take connect the jumper cable to the main negative of the bad card. And connectMoreNext we're going to take connect the jumper cable to the main negative of the bad card. And connect it to the main negative of the good cart. After our jumper cables are connected.
What charges the battery on a golf cart?
Gas golf cart accessories will also rely on battery power. However, they feature a starter/generator that will charge the battery on its own while the gas pedal is depressed. This doesn't mean a gas golf cart battery is invincible – any accessories left on while the cart isn't running will eventually kill your battery.
How to connect a black battery to a starter?
Step One: Place your starter generator in the vise or have someone hold it carefully. Step Two: Attach the 10-gauge jumper wire from F1 to A2. Step Three: Attach the negative ( BLACK) battery cable to the negative terminal on the battery.
How many volts does a starter generator need?
Battery must have 12.5 volts. DO NOT use a jump box) Vise to Hold Starter (You can have someone hold the starter if you don’t have a vise) Be sure that while you are testing the starter generator, that you keep any loose clothing, jewelry, or your fingers away from the pinion gear as it’s spins.
Can you remove a starter generator from a golf cart?
This is an off-vehicle test, so you need to remove the starter generator from the golf cart. Before you go through the trouble of removing the starter, make sure that the battery is charged and working properly.
What is a golf cart starter?
A golf cart starter primarily serves two functions; turning over the engine to start the cart and act as a key link in getting the battery charged. The starter has enough current to crank the engine. The generator converts the alternating current to direct current and recharges the battery.
Why is my golf cart generator not charging?
If your starter generator is not charging properly, it may be that the solenoid, voltage regulator or brushes are faulty. If you’ve ensured that all of these parts are working fine, the starter generator may not be drawing enough current to regenerate the battery.
What is battery regeneration?
The battery regeneration part involves the starter generator brushes, Solenoid and Voltage Regulator. The solenoid has to remain energized at all times to ensure that the return path via voltage regulator to the battery remains open. This return path is the route through which the current is returned to the battery to recharge it while the cart is running.
Why is my EZGO golf cart not charging?
This is because of the configuration of EZGO Golf carts. Almost all of the EZGO models have a setup that is foolproof to any generator failure. If the battery is not charging, it is usually the wiring or the voltage regulator. The possibility of having an starter generator that doesn’t charge the battery is very low.
How many volts does a starter generator have?
If the starter generator is showing 15 to 16 volts during the full field test, replace the voltage regulator.
What is a starter generator?
The starter generator is an electric motor that runs on the voltage drawn from the cart’s battery. After igniting and cranking the engine, when the starter generator is spinning at over 1200rpm, it starts converting the AC it produces to DC to regenerate the battery.
How to tell if solenoid is faulty?
A simple voltmeter or a multimeter set at voltage reading should be enough to identify a faulty solenoid.
What is a golf cart?
Golf carts are also known as golf cars. The term "cart", in its purest sense, refers to a vehicle that does not travel under its own power. Golf cars, however, are most commonly referred to as golf... link to Club Car DS Wiring Diagrams 1981 To 2002.
What is an electric cart solenoid?
The first generation electric cart had solenoids (or relays) that had all terminals on one end of the unit. These solenoids are no longer available and are replaced with a model with terminals on both ends. Below is the retrofit for replacing these with a contemporary solenoid.
What was the first Yamaha cart?
Yamaha’s premiere cart in 1979 was the G1A Model J10 Gas-powered vehicle that featured an Autolube Oil Injection System to supply oil to the engine in precise oil-to-gas ratios. This eliminated the premixing of the oil and gas and improved combustion, oil consumption, and carbon buildup. In 1980, Yamaha introduced the G1E 36 volt Electric J14 series.
