how to test a voltage regulator on a harley davidson golf cart

by Mr. Larry Stracke Published 3 years ago Updated 2 years ago

How do I know if my Harley voltage regulator is bad?

0:214:10How to Test a Harley Davidson Voltage Regulator - YouTubeYouTubeStart of suggested clipEnd of suggested clipLight up your lights are dimming your dash lights are going off or dimming things like that are allMoreLight up your lights are dimming your dash lights are going off or dimming things like that are all symptoms you may have a possible bad regulator.

How do you test a golf cart voltage regulator?

Once the new voltage regulator is installed, it is time to test whether it is running correctly. Use a voltmeter and connect it to the terminals of the battery. The reading should be 12.6 volts, provided that there is no spin. Then, press the acceleration pedal on the golf cart.

How do I test a voltage regulator with a multimeter?

0:232:18How to Test a Car Voltage Regulator - YouTubeYouTubeStart of suggested clipEnd of suggested clipAnd what you do is you put your multimeter clamps directly on the battery. Terminals. Positive redMoreAnd what you do is you put your multimeter clamps directly on the battery. Terminals. Positive red to positive and black to negative. And you set it to voltage.

What are the symptoms of a faulty voltage regulator?

Bad Voltage Regulator SymptomsToo High Voltage in the Battery.Dead Battery.Battery Light or Check Engine Light.Inconsistent Operation of Electrical Components.Vehicle Dies While Running.Dimming/Pulsing Lights.

How do I know if my voltage regulator is bad on my golf cart?

Use a jumper and connect it from the ground of the cart to the stud of the starter generator. If the voltage is 15VDC or more, then the voltage regulator is faulty.

How do you test a voltage regulator in a circuit?

We take the probes of the multimeter and place the positive probe (normally the red probe) on the input pin of the voltage regulator and the negative probe (normally black probe) on the ground pin. The voltage that we should read should be higher than the voltage the regulator is rated to output.

How do I know if my motorcycle voltage regulator is bad?

To check the regulator, connect the meter leads to the bike's battery as it's running. The reading should not be higher than 14.5 volts or lower than 13.5 volts. If the reading is higher, this means the battery is overcharged and you may need to replace the regulator rectifier.

How do you test your regulator?

Follow these steps to test your voltage regulator:Step 1: Set The Multimeter To Voltage. Ensure your multimeter is on the voltage setting. ... Step 2: Connect The Multimeter To Your Battery. ... Step 3: Check The Multimeter. ... Step 4: Turn Your Vehicle On. ... Step 5: Rev The Engine. ... Step 6: Check The Multimeter Again.

How many volts should a Harley stator put out?

AC Output Check: Start motorcycle and change Voltmeter to AC volts. Probe both stator wires with your meter leads. The motorcycle should be putting out approximately 18-20 ACV per 1,000 rpm.

What can cause a voltage regulator to fail?

It might be due to a host of other causes, including forgetting to switch off your lights, a problem with the alternator, or simply an old battery that needs to be replaced. But it could also be because of poorly managed current due to a bad voltage regulator.

How do you fix a voltage regulator?

0:032:16how to repair a voltage rectifier regulator charging system - YouTubeYouTubeStart of suggested clipEnd of suggested clipBefore you put it back on with the back off you can inspect the electronics. This is the diodeMoreBefore you put it back on with the back off you can inspect the electronics. This is the diode bridge. And this is the rectifier shim the rectifier shim ensures you have properly gapped electrons.

What is a golf car voltage regulator?

A golf car voltage regulator is one of the most important parts of a golf cart. The voltage regulator helps to limit and regulate the power that is sent to a golf cart battery for its recharge. When you start your golf cart, the starter generator performs the role of a starter motor and causes the engine to start.

Where is the voltage regulator on a golf cart?

The voltage regulator of your golf cart is usually located under the cart seat along with the batteries. It’s fitted in place using latches or bolts. In an EzGo golf cart, the voltage regulator is often located inside a black plastic shield that is shaped like a pyramid and has three wires of different colors.

How many wires does a golf cart voltage regulator use?

Two types of voltage regulators are commonly used. One type makes use of three wires while the other type comes with four wires. Irrespective of the kind of voltage regulator that you opt for, it’s essential that the wires of the voltage regulator in your golf cart are connected correctly.

Why is my golf cart battery not charging?

In most cases, a motor problem is likely to be due to a faulty voltage regulator. Having a faulty voltage regulator can lead to other problems as well, such as overcharge causing electrical components to burn out or inability of the golf cart battery to retain a charge.

How many volts does a golf cart battery use?

As a result, the batteries experience a backflow of a constant voltage of 14 volts.

How to check voltage on gas club car?

You can follow the steps given below to test the voltage regulator of your gas club car. Connect the voltmeter to the battery and get the golf cart running. You can consider applying the hand brake to prevent rolling. Check if the voltage rating is between 14 volts and 16 volts.

Why is my golf cart overheating?

Improper pin connections are one of the most common reasons for your golf cart voltage regulator to get overheated. Positive ground regulators should have the pins in the order of input, ground, and output from left to right. For negative regulators, the order is ground, input, and output.

How to tell if Harley voltage regulator is bad?

Another telltale sign that you’re dealing with a faulty Harley voltage regulator is that the instrument cluster fails to turn on. You should notice this after putting in the key and turning it to the on position. With a faulty regulator, none of the normal lights will illuminate.

Why is the Harley voltage regulator needed?

It’s required by the motorcycle electronic system to display the engine speed and other important vitals. Problems with the Harley voltage regulator will eventually lead to issues with information being properly displayed. This includes the state of your motorcycle’s engine, it’s running condition, speed, and everything else that’s revealed on ...

How to check if a regulator is leaking?

If the regulator is leaking voltage, the battery will also be leaking voltage. This is a condition that’s easy to test. Using a multimeter, clip the test light on to the negative terminal of your battery. Next, unplug the regulator to get an accurate voltage reading. Using the test light, touch each of the regulator terminals one at a time.

What is a voltage regulator?

What is the Harley Davidson Voltage Regulator? The Harley-Davidson voltage regulator is an electrical component that controls the amount of voltage going into the instrument gauges, speedometer, and gauge cluster. It’s required by the motorcycle electronic system to display the engine speed and other important vitals.

Why does my bike gauge flicker?

Since it’s the regulator that supplies power to the gauges, the gauges will start to dim and flicker if there’s an issue with the power supply . It can be difficult to notice this issue during the day, especially if you’re riding in bright conditions.

Why is my bike's instrument cluster disabled?

While you’ll probably be able to turn on the bike and go for a ride, you’ll be missing out on the instrument cluster information .

Do Harley Davidson motorcycles come with voltage regulators?

This will allow you to discover issues and symptoms before they become serious problems. Regardless of the Harley-Davidson you’re riding, all of them come with voltage regulators.

How to check if a regulator is toast?

To check the regulator unplug it from the stator. Take a test light and clip it to the negative terminal of the battery and then touch first one pin and then the other on the plug that goes to the regulator. If you get even the slightest amount of light from the test light the regulator is toast.

How many volts should a bike meter read?

Set the meter to read A/C volts higher than 30 volts (the scale setting for voltage should always be higher than the highest voltage you expect or you may fry the meter). Start the bike, and measure from one pin to the other on the plug (DO NOT cross the multimeter probes! - touch them to each other).

How many amps does a battery have?

Battery is typically rated at 19 amp hours and 270 Cold Cranking Amps (CCA). Step 2. To check the regulator unplug it from the stator. Take a test light and clip it to the negative terminal of the battery and then touch first one pin and then the other on the plug that goes to the regulator.

What type of electrical system does a Harley Davidson have?

The Harley Davidson gasoline cart has a 12-volt electrical system utilizing a combination starter motor/generator unit built into the engine crankcase, in conjunction with a control switch-box-regulator unit and a storage bat­tery using a negative grounded system.

What is a golf cart?

Golf carts are also known as golf cars. The term "cart", in its purest sense, refers to a vehicle that does not travel under its own power. Golf cars, however, are most commonly referred to as golf... link to Club Car DS Wiring Diagrams 1981 To 2002.

What are the components of a motor control system?

Components of the control system are the reversing switch, solenoid switch, adjustable field resistor or regulator, micro-switch and a key switch.

How does a generator work when engine speed exceeds starter generator speed?

When engine speed exceeds starter generator speed, the shunt field coils (G) are excited and the current generated in the armature is utilized for the ignition system and charging the battery . The generator output is limited by the adjustable resistor or regulator (9), which con­trols the strength of the magnetic field produced by the shunt field coils (G). The generator voltage increases with engine speed and as soon as the rated level (approximate­ ly 15 volts) has been reached, charges the battery and in­creases with engine speed to its maximum value con­trolled by the voltage regulator. The prescribed charging rate at governed speed is set by means of a variable resistor or is controlled by the voltage regulator.#N#On models equipped with field resistor, a diode acts to bleed off the voltage generated by the operation of the cart when coasting with solenoid contacts open (i.e.ac­celerator pedal released).
