Full Answer
How do you put a strut on a piston?
Punch the strut nut in a clockwise direction until it stops moving. Put the Spring on. Put the top spring seat, followed by the strut mount, insert the bushing then the washer, and lastly place the nut on the piston and tighten until you can't turn it any more with out spinning the piston.
How do I install the strut mount?
Insert the assembly in to the tower, and supporting the assembly with one hand position the strut mount in the holes and pushing up catch a nut on a few threads. Then place the other nut on the strut mount and tighten fully.
How do you remove the front struts?
Using a pair of Vice Grips at the very top of the strut, and you should use a curved jaw type clamp them as tight as you can get them. Use the Ground as the hold fast as you loosen the strut nut. Be sure that you have spring compressors on and tighten enough so that the top perch is free of the spring, Failure to do so can KILL YOU.
How much torque do I need to tighten the strut mount?
With the Vice Grips firmly on the top most of the shaft, you can now tighten the top strut mount to the 59 ft/lbs of torque that you need.
Can you drive with a broken strut mount?
Can I drive with a damaged strut? No. It needs to be repaired as soon as possible. A strut works by absorbing the bounce of your car driving over bumps in the road.
How do you fix a broken strut mount?
1:313:26How to Inspect and Replace Strut Mounts on Your Car - YouTubeYouTubeStart of suggested clipEnd of suggested clipAnd put the spring assembly back on top of it. Then put the little collar bearing on top it comesMoreAnd put the spring assembly back on top of it. Then put the little collar bearing on top it comes with the kit then get the new strut mount. Slide that on top.
What holds a strut in place?
As the name (strut mount) implies, it's a component that attaches the suspension strut to the vehicle. In addition, it insulates the tire noise & vibrations from the vehicle. Many (front) strut mounts also contain a bearing or bearing plate that serves as the steering pivot. A strut mount is like a sandwich.
Is strut mount replacement necessary?
Strut mounts don't need any maintenance. They don't need to be replaced unless they are worn out or there is some other problem with them. There are several reasons why strut mounts may need to be replaced. The most common is when a worn out strut mount produces a clunking or rattling noise.
How do you lubricate strut mounts?
0:071:26How to Lube Upper Strut Bolts - YouTubeYouTubeStart of suggested clipEnd of suggested clipOil or whatever you have as far as a breakaway style oil wd-40 pb blaster liquid wrench somethingMoreOil or whatever you have as far as a breakaway style oil wd-40 pb blaster liquid wrench something like that you're going to want to fill this whole assembly up.
Can a strut mount be fixed?
The strut has to be fixed on a capable mount for an optimal level of efficiency. The strut mounts are vital to the front wheel alignments and reduce noise/vibration transfer. The strut mounts wear over time because of the loads resting on them, calling for a scheduled replacement.
Can you DIY struts?
These assemblies allow you to replace both of your front struts yourself in less than two hours. You'll have to get an alignment done afterward (about $100), but you'll still save about $300 by doing the job yourself. You'll need rust penetrant, wrenches, a pin punch or large screwdriver, and a thin piece of plywood.
How do you fix a rusted strut tower?
8:2012:03FIXING S13 STRUT TOWER RUST! - YouTubeYouTubeStart of suggested clipEnd of suggested clipJust um spot weld these panels on like the original.MoreJust um spot weld these panels on like the original.
What connects to the strut?
The bottom of the strut usually attaches to the steering knuckle, and the top of the strut is connected to the vehicle body through an upper strut mount. With most strut suspensions, the upper strut mount replaces the upper control arm, upper ball joint, control arm pivot shaft, and control arm bushing.
What can cause a strut mount to break?
While struts usually last a long time, strut mounts can go bad due to the age of the vehicle and natural wear and tear. Other causes of a faulty strut mount include impact damage and contamination. Minor accidents and bad weather may affect the strut mount and cause it to fail prematurely.
How much is a strut mount?
An aftermarket shock and strut mount costs anywhere between $50 and $250. Prices may vary depending on the brand you choose and other product specifications. Labor costs for this type of repair range from $50 to $200.
Do struts mounts affect alignment?
Strut removal & installation potentially changes the position of the tire alignment. Some struts have adjustment slots to perform the alignment with. All struts affect alignment in some way so it's best to check the specific vehicle service manual and specifications.
How much do strut mounts cost?
Replacing a strut mount will cost you somewhere in the range of $120 to $250 total (parts & labor). The strut mount itself will only cost around $40 to $100 in parts.
How do you tell if strut mount is bad?
Signs of a Bad Strut MountWeird Noises. If you hear clunking or squeaking coming from the suspension system while driving, this could mean the mount has worn out. ... Uneven Tire Wear. ... Excessive Vibration. ... Steering Issues. ... Corrosion. ... Worn Rubber. ... Excessive Movement. ... Worn Struts.More items...•
How do you replace a top mount?
3:026:53How-to install a top strut mount - YouTubeYouTubeStart of suggested clipEnd of suggested clipOkay so as you can see here the spring is under tension meaning. It's has significant energy storedMoreOkay so as you can see here the spring is under tension meaning. It's has significant energy stored up which could cause serious injury if released to prevent this you'll need to securely and safely
How do you replace strut mount bolts?
0:001:54Removing Front Struts & Upper Mounting Bolts - YouTubeYouTubeStart of suggested clipEnd of suggested clipAnd removing the upper mounting bolts on the bearing plate. What you're going to want to do is takeMoreAnd removing the upper mounting bolts on the bearing plate. What you're going to want to do is take and grab a hold of the strut. And pull the knuckle out away from the the joining surface.
Why does my strut make a clunk?
This noise happens when the strut is fully extended. When you turn, you might get some noise and you might not. If your strut mounts are badly worn, you’ll probably get a clunk noise when you turn as well.
What does it mean when your struts rattling?
As you drive over any surface that creates travel in your struts, you’ll probably hear a rattling noise from the front. It can happen on just slight suspension travel, over only bigger bumps, or it could happen all the time. Over larger bumps or potholes, you’ll get a loud clunk.
Can a strut punch through a strut?
In extreme conditions, the strut can punch through the top of the strut mount, maybe even causing an accident or crash. The issue is the material used for the upper strut mounts. Over time, the rubber used to make the strut mounts compresses under the weight of your car.
Is wheel alignment accurate?
This travel means your wheel alignment is never accurate as your wheel is free to move around. The evidence is in your tire wear – when your strut mounts are worn, you’ll quickly notice premature wear on the shoulders of your tire.
