What is a PDS cart?
PDS (Precision Drive System) is E-Z-Go's current regen system (prior to the introduction of the new RXV carts of course). It can be programmed to have 4 different levels of regen via "chips" (actually molex connectors with differing wire loop combinations) that select the different performance parameters.
What is the difference between EZGO PDS and TXT golf carts?
What is the difference between EZGO PDS vs Series TXT golf carts? The PDS (Precision Drive System) cart is a TXT. A PDS TXT is a regen TXT that has regenerative braking.
What is the difference between a PDS and TXT?
A PDS TXT is a regen TXT that has regenerative braking. The other present model of a TXT is a Fleet TXT or series which has no regenerative braking and is used a lot on golf courses.
What is the difference between DCS and PDS?
DCS (Drive Control System) is E-Z-Go's first attempt at a regenerative cart. The regen feature cannot be defeated or modified without replacing expensive parts. PDS (Precision Drive System) is E-Z-Go's current regen system (prior to the introduction of the new RXV carts of course).
What is the difference between EZGO DCS and PDS?
2:136:50How to tell what EZGO TXT you have. EZGO Lingo - YouTubeYouTubeStart of suggested clipEnd of suggested clipSecond drive control system dcs. Still going to have the lever under your legs with a run tow switchMoreSecond drive control system dcs. Still going to have the lever under your legs with a run tow switch pds pds is going to have the rocker switch that's what goes on your dash.
What does PDS mean on EZGO?
EZGO PDS (Precision Drive System) Electronic Speed Controller Performance Plugs.
How do I test my EZGO PDS controller?
PDS TEST AT THE 10 PIN CONNECTOR OF THE CONTROLLER Place the (+) probe on the black wire terminal of the connector. The reading should be slightly above 14 volts but LESS than 16 volts. If the voltage is below 14 volts, the Throttle Sensor MAY be faulty. Above 16 volts, the controller MAY be faulty.
What is a DCS golf cart?
For EZ-GO Regen carts, you must determine if it is a DCS (Drive Control System) or PDS (Power Drive System) cart. This can be determined by the type of Forward/Reverse switch and controller. Be advised, more often than not, the model type is written right on the cart itself.
How can I make my 48V EZGO golf cart faster?
6 Ways You Can Make a Golf Cart FasterAdd More Torque to Your Golf Cart.Upgrade Your Golf Cart's Motor.Improve the High-Speed Controller of the Cart.Add Better Golf Cart Tires.Use a Higher Powered Golf Cart Battery.Watch the Weight in Your Golf Cart.
What is DCS on EZGO?
in 2 drive systems. Series or DCS. DCS has a toggle switch on the controller cover.
How can I make my electric golf cart go faster without upgrading?
How to Make an Electric Golf Cart Faster Without UpgradesWash Your Cart Properly. ... Inspect the Batteries. ... Refill the Battery Water. ... Check the Gas Pedal and Linkage. ... Measure the Tire Pressure. ... Charge Up Your Battery Unit. ... Lighten Up Your Cart's Weight.
Is there a reset button on a EZGO golf cart?
Look in the area where several electrical wires enter the motor and locate a small red button. This is the reset button. Push the button to reset the motor.
How do I reset my EZGO controller?
Reset the battery cable Unplug the negative battery cable (the black wire) before beginning any work on the speed controller. Once disconnected, you should remove the speed controller cover and then reconnect the negative cable.
How do I know if my golf cart is AC or DC?
The easiest way to know if your golf cart has an AC motor is to read its description online. Check out the various items highlighted by the manufacturer and find the engine listing. Here, you'll find a description of the engine that should read “AC” or “DC.”
How do I know if my Club Car has an ADC motor?
If you have questions regarding if your Club Car has a IQ system with ADC motor or a GE motor please contact me. The easiest way to tell is by checking the serial number prefix. If your serial numbers starts with: AQ, CE, FD, HD, PE, or PQ then you have a cart with a IQ system.
What is a DCS motor?
The DCS is often called upon to start and stop motors, especially compressor motors. The commands can be initiated by the board operator or by logic. In either case, the motor must be protected from potentially damaging conditions. External systems, like Bentley-Nevada and Multilin, provide motor protection.
Flip the Maintenance Switch
Both types of E-Z-GO controllers have a maintenance switch which should be flipped when servicing or troubleshooting. The switch is under the seat and should be changed to "Tow-maintenance" mode.
Reconnect the Battery Cable
Disconnect the black battery cable (negative) from the battery, open the cover to the speed controller and then reconnect the negative battery cable.
Inspect Wires and Check Voltage
Inspect all wires to ensure that they are attached and well connected, there are no breaks, corrosion or interference with the wires. Take the reading of the battery voltage by connecting the positive and negative probes to the battery. Write down the voltage reading.
Test the Solenoid
Place the positive probe on the solenoid post that is closest to the battery. The reading should be equal to battery's voltage. If not, there is a wiring issue in the solenoid. Connect the positive probe to the other post and take a reading.
Check Power Output From the Controller
Connect the negative probe to the controller's M terminal and positive probe to the B+ terminal. Press the accelerator and watch to see if the voltage increases. It should increase from a reading of 0 to the full voltage of the battery. If the motor is not turning, the problem may be in the directional switch or motor.
Next Steps
It's important to remember that if you are not fully confident in the work you are trying to perform on your E-Z-GO golf cart, consult with your local E-Z-GO dealer to be sure your work gets done properly.
