Full Answer
What is the bolt pattern on a VW Golf tire?
Volkswagen Golf wheel specs and tire sizes (2008 – 2014) Bolt pattern (PCD): 5 × 112 Center Bore (CB): 57.1 Thread size (THD): 14 x 1.5
What is the wheel size of a VW Golf?
Volkswagen Golf wheel specs and tire sizes (2008 – 2012) Bolt pattern (PCD): 5 × 112 Center Bore (CB): 57.1 Thread size (THD): 14 x 1.5 Diameter: 15 — 17 Width: 195 — 225 Aspect ratio: 45 — 65 Smallest — Largest tire size: 195/65R15 — 225/45R17
Do golf wheels have bolt holes?
The lug holes do great work for the Golf wheels by keeping them attached to the car. These bolt holes are set in a circular pattern, that is why people call it a bolt pattern. The vehicle can only get the wheels with the same lug pattern. Moreover, various types of lug hole seats are constructed to work only with the fitted lug type.
What is a bolt pattern on a golf?
Not so many car enthusiasts know that the bolt pattern (also referred to as a lug pattern) is the measurement that determines the diameter of an abstract circle that was formed with the lug centers on the car wheel. When swapping the wheels you have to know the correct Golf lug pattern, as not all rims may be a bolt-on match.
What size are VW wheel bolts?
Additional informationHex Size17mm HexThread SizeM14 x 1.5Thread Length27mm ThreadSeatRadius SeatTypewheel Bolts3 more rows
What is the bolt pattern on a VW Golf?
5x112 mmAdvertisementBolt Pattern5x112 mmHub Bore57.1Nut or BoltboltNut Bolt Thread TypeM14x1.5Nut Bolt Hex173 more rows
What is the bolt pattern on a 2012 VW Golf?
The 2012 Volkswagen Golf TDI 4-Door bolt pattern is 5-112 mm. This means there are 5 lugs and the diameter of the circle that the lugs make up measures 112 mm or 4.4 inches across.
What size are Mk7 GTI lug nuts?
Thread Size: M12 x 1.5. Hex Size: 17 mm.
What cars use 5x112 bolt pattern?
Bolt pattern 5x112 What cars have a 5x112 bolt pattern?Aiways (2) U5 (2020-2021) U6 (2021-2022)Alfa Romeo (1) Alfa 6 (1979-1986)BMW (31) ... BMW Alpina (6) ... Bentley (5) ... Borgward (5) ... Brilliance (1) ... Chery (1)More items...
Does 5x100 fit 5x112?
There is not. If the offset is smaller allowing you to use spacers then you could buy spacer set that have hub mounting pattern 5x100 and rim pattern 5x112. Does not work with original offset as spacer will push the rim out too much.
What is the bolt pattern on a 2015 Volkswagen Golf?
The 2015 Volkswagen Golf TDI bolt pattern is 5-112 mm. This means there are 5 lugs and the diameter of the circle that the lugs make up measures 112 mm or 4.4 inches across.
What stud pattern is a mk4 Golf?
Volkswagen - Golf 4 (1997 - 2003)PCD:5x100Center bore:57.1Offset:38Mounting:Bolt - 14 x 1,50Wheel torque steel:120 Nm / 89 ft-lb2 more rows
What is the bolt pattern on a 2006 VW Jetta?
The 2006 Volkswagen Jetta 2.5L bolt pattern is 5-112 mm.
What size are the lug nuts on a 2012 VW Jetta?
Thread Size: M14 x 1.5. Overall Length: 48.26 mm. Thread Length: 25.4 mm. Head Diameter: 0.79".
What size rims are on a 2012 VW GTI?
18″ diameter, 7.5″ width2012 Volkswagen GTI / Wheel size
What size rims are on a 2008 VW GTI?
17″ diameter, 7″ width2008 Volkswagen GTI / Wheel size
What is offset on a wheel?
Wheel offset is the distance from the mounting surface of the wheel to the true center line of the rim. A positive offset means the mounting surface of the wheel is positioned in front of the true center line of the rim / tire assembly. This in effect brings the tire in to the fender well more.
What is a hub bore?
Hub Center Bore: Relates to the center hole in the wheel that centers the wheel on the hub of the car. Since most wheels are mass produced, they have a large center bore to accommodate several different vehicles. If this is the case, it is recommended that you use a hub ring. Hub rings are hard plastic or metal ring that fits between the wheel and the vehicle. This centers the wheel perfectly on the hub ensuring that there is no run out when the wheel is installed on to the vehicle. Without hub rings it is possible to get vibrations even if the wheel / tire assembly is perfectly balanced.
Volkswagen Golf SportWagen specs
While trying to complete a tire rotation on your own or maybe, you simply decided to upgrade the stock wheels with the aftermarket counterparts, you will find yourself chasing the correct Golf SportWagen bolt pattern.
What is the Golf SportWagen Bolt Pattern?
Not so many car enthusiasts know that the bolt pattern (also referred to as a lug pattern) is the measurement that determines the diameter of an abstract circle that was formed with the lug centers on the car wheel. When swapping the wheels you have to know the correct Golf SportWagen lug pattern, as not all rims may be a bolt-on match.
Golf SportWagen Bolt Pattern Torque Specifications
Also, when doing the tire rotation, a car owner needs to check the Golf SportWagen owner`s manual or the official website for the torque specs. But we have another option for you – informative and neat charts, that were prepared by our specialists.
