Full Answer
How do I find the right spark plug for my golf cart?
Use this Golf Cart Spark Plug Reference Chart to find the right spark plug for your gas powered golfcart. Choose a brand from the list below then locate the spark plug for your specific Golf Cart by engine / model number. Club Car| Columbia Par Car| Cushman| E-Z-Go| Harley Davidson| Yamaha Club Car Model Plug Gap Champion NGK Mega-Fire Torch Bosch
Where is the tow switch on an EZ GO golf cart?
Lift your E-Z-Go cart’s front seat. You will see the tow/run switch; turn it to tow instead of run. Look for wires labeled 1, 2, 3, 4 and ensure that wire 1 connects to wire2 and where wire3 connects to wire 4.
What do you need to know about E-Z-GO golf carts?
The E-Z-Go golf cart is one of their premier products and is in use in several golf courses. If you are planning to purchase a fleet for your company, you need to know how they work and make necessary repairs. Here is a comprehensive guide on maintenance and troubleshooting E-Z-Go carts.
How many volts do you put on a EZ GO battery plug?
Triangle-shaped plugs do not have a reed switch, so if it fails, apply 48 volts to the wire at the receptacle to bypass the charger interlock. Your E-Z-Go golf cart solenoid has four terminals, two large ones and two small ones.
How do you change the spark plugs on a EZGO golf cart?
0:011:31How to Change the Spark Plugs in your Golf Cart | Golf Cars UnlimitedYouTubeStart of suggested clipEnd of suggested clipWe're gonna go ahead and remove the spark plug we're gonna pull the cap off. We use a spark plugMoreWe're gonna go ahead and remove the spark plug we're gonna pull the cap off. We use a spark plug socket. And we're gonna loosen. And remove the spark. Plug.
How many spark plugs does a EZGO golf cart have?
Two spark plugs are used in the engines described above. The proper gap is . 028". This is a NGK BP4ES.
Do gas golf carts have spark plugs?
The spark plug is a small plug inside the engine of your gas-powered golf cart that ignites the fuel to make your cart go. Sometimes you may have to replace your plug when it becomes worn. Doing so is a simple process, though one which should be done carefully.
Do electric golf carts have spark plugs?
Electric golf carts are the kind you see on most golf courses. They are quieter and cleaner to run, and you don't have to change the oil, fuel filter, air filter or spark plug. Instead, you want to pay attention to the battery.
How much oil does a ezgo golf cart hold?
The typical engine oil which is used in most of the EZGO carts is 10W-30 and 10W-40. The oil capacity of an EZGO cart is around 6 cups. It is also highly recommended that the engine is checked after a day's usage to make to the perfect time to change the oil.
How do you tune up a gas golf cart?
1:068:02How to Tune Up Your Gas Golf Cart - YouTubeYouTubeStart of suggested clipEnd of suggested clipYour oil plug and then you're also going to need a socket to remove your spark plug. If you want toMoreYour oil plug and then you're also going to need a socket to remove your spark plug. If you want to mention here that. This here is a an oil filter wrench they come in a few different.
What does ezgo igniter do?
EZGO Ignition Switch, Ignitor, Coil Parts Ignition coils transfer voltage from your battery into spark for your engine to fire. We carry ignition coils for EZGO TXT, RXV, Marathon, and ST350 Workhorse golf cart models.
Why is my golf cart not firing?
First, try this: turn the key switch on, hit the accelerator, and check for a clicking noise. If you don't hear clicking, it's time to take a look at your cart's batteries. Make sure the battery is fully charged and the terminals are cleaned and secure. Next, see how the water level in the battery is holding up.
How do you check the igniter on a EZ Go golf cart?
Take the voltmeter's black and red probe and place it on the –ve and +ve terminal of the coil. Take the readings. It should be between 3.7-5.2 ohms. If outside the range, the coil should be replaced.
How fast does an ezgo golf cart go?
And the fastest electric EZGO is the 2Five that goes 25 mph. And the fastest EZGO gasoline golf cart also only goes 19 mph.
Does an electric golf cart have oil?
Electric golf carts require less for several reasons: You don't have to change any oil as they don't need oil. With no spark plugs or starter belts, you have fewer components to replace. Electric golf carts have fewer than fifty moving parts, whereas most gas ones have more than 1,000.
How long do electric golf carts last?
between 20 and 40 yearsThe average lifespan of an electric golf cart is between 20 and 40 years. However, it is important to keep in mind that if you do not keep up with the proper maintenance, there is no guarantee that the electric golf cart will last even ten years.
How does a gas golf cart start?
In a gasoline-powered golf cart, the engine starts when you step on the gas pedal, and it shuts off when you take your foot off the gas. That feature helps save gas, cuts down on emissions and helps keep the course quiet, too.
How does a golf cart ignition work?
As it spins, it sends this electrical charge directly to the ignitor on your cart. Once your ignitor is hit by this charge, it boosts the signal to make it stronger. The idea here is to make the charge strong enough to ignite the gasoline in your cart's engine as it runs.
What does an ignitor do on a golf cart?
The ignitor boosts the signal and sends it to the ignition coil. The coil then creates the large spark that goes to the spark plug and fires the gas mixture in the cylinder. Ignitors can be the cause of a weak spark or they may fail completely and then the coil cannot create any spark at all.
How do you check the coil on a Club Car golf cart?
Get the negative terminal of the golf cart batteries disconnected with the help of a wrench. Get the wires which lead to the ignition coil disconnected. Check to confirm if the thicker wire is attached to a wiring harness that can be unplugged. The thinner wire acts as a pin connector which may be pulled out by hand.
Do E-Z-Go Golf Carts have titles?
E-Z-Go Golf Carts, unlike vehicles, do not have a title, but they do have serial numbers. If you are buying a golf cart, it is essential to check the serial number to ensure you do not buy a stolen one. Each E-Z-Go Golf cart has a unique serial number that you can use to identify your golf cart.
Where is the E-Z-Go Cart Serial Number
As mentioned above, all E-Z-Go Golf carts have unique serial numbers. These numbers are essential when buying replacement parts for your golf cart. Textron Specialized Vehicles has been building golf carts for a long time, and the serial numbers are placed on different parts of the golf carts.
How do I push my E-Z-Go Golf Cart?
It can be frustrating when your battery is flat and your golf cart will not roll. To push it to the nearest charging or gas station, you need to release the motor brake. Follow these easy steps to do that.
Why does my E-Z-Go golf cart not move
There are several reasons why your cart refuses to move, but you should check the battery before anything else. If the battery is charged, here are some other reasons why your golf cart will not move.
Are all E-Z-Go Golf carts electric?
No, there are both electric and gas-powered E-Z-Go Golf carts available. Bear in mind that there are several models you can drive on the street, but those are all-electric. These electric models run on batteries that you have to charge at least every 24 hours, depending on how much you use them.
How to tell the Assembly year of my E-Z-Go golf cart
The placement of serial numbers is discussed above, and you will find the manufacturer’s number right next to it. The manufacturer’s number consists of one letter and 3 or 4 numbers. The last two numbers indicate the last two digits of the year of assembly.
How to service E-Z-Go Golf Cart
Like all vehicles, E-Z-Go golf carts require regular maintenance to enhance longevity and performance. You should ensure that your golf cart is serviced after every six months of use. That will ensure that you spot problems and repair them early, which will help reduce repair costs. Here are essential guidelines for E-Z-Go golf cart maintenance.
Step 1: Air filter
The canister air filter is accessed by raising and lifting out the cart seat, locating the cylindrically shaped airbox with a cap on the end, and unsnapping the two holding clips on each side. Remove the lid and then the filter. Installing your new air filter is the reverse of these steps.
Step2: Spark Plugs
Despite the many years of EZGO carts, there are only two sparkplugs that EZGO carts use, BPR4ES and BPR2ES; the latter for Kawasaki engined EZGO carts.
Step 3: Fuel
The fuel filter is located in line between the fuel tank and the fuel pump. If the housing is clear plastic, make sure that the fuel inside is not dark amber or discolored from age.
Conclusion
All of these adjustments can be made on your EzGo Golf Cart without spending more than your time and a tune up kit.
How to remove fuel filter from fuel pump?
To remove the filter, disconnect the hose from the fuel pump by using a pair of pliers to squeeze the clamp ends together and sliding the expanded clamp further down the line. Raise the hose up and allow any excess fuel to drain back into the fuel tank.
What is a golf cart?
Golf carts are also known as golf cars. The term "cart", in its purest sense, refers to a vehicle that does not travel under its own power. Golf cars, however, are most commonly referred to as golf... link to Club Car DS Wiring Diagrams 1981 To 2002.
What color should a ceramic insulator be?
The ceramic insulator should be ivory colored, light brown to brown would indicate the fuel mixture is too lean. If it is black in color, you might be running too rich of a fuel mixture, requiring an adjustment to the air/fuel mixture screw.
Where is the second filter on a carburetor?
Return the filter to the gas line and secure it with the clamps. Sometimes there is a second filter located underneath the carburetor facing the front of the cart. Check to see if you have one and make sure it is also clear of deposits.
